20inch Water Flow 4500m3 Cutter Suction Dredger with Anchor Boom

Qingzhou Set Sail Dredging Equipment Machinery Co., Ltd.
  • Type：Cutter Suction Dredger
  • Power Type：Diesel
  • Cyclone Type：Hydrocyclone
  • Slot Type：CTS
  • Customized：Customized
  • Condition：New

Base Info

  • Model NO.：QHCSD-205
  • Warranty：1year
  • After-sales Service：Lifelong
  • Capacity：900m3
  • Dredging Depth：16m
  • Discharge Distance：2000m
  • Main Engine Power：1491kw
  • Auxiliary Engine Power：298kw
  • Discharge Pipe Diameter：450mm
  • Cutter Head Diameter：1700mm
  • Cutter Head Power：170kw
  • Pulling Winch Force：80kn
  • Swing Winch Force：80kn
  • Total Weight：245t
  • Total Fuel Consumption：268L,H
  • PLC System：Siemens
  • Hydraulic System：Rexroth
  • Total Length：38m
  • Transport Package：Canvas
  • Specification：Water flow 4500m3
  • Trademark：Set Sail
  • Origin：Qingzhou City Shandong Province China
  • HS Code：895100000
  • Production Capacity：1500 Sets ,Year

Description

            Set sail factory is found in 1992 . it is one of the leader of china dredging machinery equipment industrial. We have manufacture experience more than 20 years so far. Our mainly product : all kinds power of cutter suction dredger (electric hydraulic ) jet suction dredger trailing suction dredger wheel suction dredger chain bucket dredger chain bucket mining dredger land mining machinery multi-function service working boat sand transportation boat sand wishing machinery etc. We can according to customers requirement to make the design and customize the product .
 20inch Water Flow 4500m3 Cutter Suction Dredger with Anchor Boom20inch Water Flow 4500m3 Cutter Suction Dredger with Anchor Boom
2. Principle drawing :
20inch Water Flow 4500m3 Cutter Suction Dredger with Anchor BoomSimple to introduce the principle :

Hydraulic cutter head rate to add the solid concentration. mixture through the suction pipe into the discharge pipe by the pressure pump to arrived the destination .( power is from hydraulic  electric or both together)

 3. product :( from produce start to the end ) :
20inch Water Flow 4500m3 Cutter Suction Dredger with Anchor Boom                 From the product start we purchase the CCS standard plate and to others original material to ready for manufacture .all device adopts high quality and famous brand . normal diesel engine from American Cummins.we can offer the other engine brand Cater . Wechai so on .Slurry pump from Shijiazhuang industrial pump . Siemens PLC system . Hydraulic system from Germany Rexroth etc.
 4.product image:
20inch Water Flow 4500m3 Cutter Suction Dredger with Anchor Boom
5.Detailed introduce:

20inch Water Flow 4500m3 Cutter Suction Dredger with Anchor Boom6.  Dredger in abroad:
20inch Water Flow 4500m3 Cutter Suction Dredger with Anchor Boom        Set sail workers try the best do each detail perfect from the point to the face . provide the high quality to our customer let customers spend the lowest cost the get the biggest value. We can offer timely and high efficiency service let our customer do not worry anything .

 8.Packaging and transportation detail shows:
20inch Water Flow 4500m3 Cutter Suction Dredger with Anchor Boom9. 22inch basic parameter:Item ParameterCapacity (cubic meter )900m3Water  flow (cubic meter )4500m3Maximum dredging Depth( meter)16m Discharge distance (meter)2000mEngine power and brand (kw)1491kwMain Engine fuel consumption (Liter)160LCutter head diameter(mm)2000mmCutter head power(kw)170kwPLC system SiemensHydraulic control system RexorthSlurry pump brand and type Shijiazhuang WN500Discharge pipe diameter (mm)500mmTotal length (meter)38mTotal width (meter)8.5mTotal hight (meter)2.5mTotal weight245T10.Basic cutter suction dredge model and parameter:NO. ItemWater flow (m3)Capacity(m3)Dredging depth(m)Discharge distance (m)Pump type Mainly engine power(kw)8 inch 800 1608800WN20022010 inch 100020091000WN25033612 inch 1500300111200WN35055914 inch 2000400121500WN30063416 inch 2500500131500WN35074618 inch 3500700151500WN45089520 inch 4000800152000WN500126822 inch 4500-5000900-1000162000WN500149124 inch 60001200172000WN550219026 inch 70001400202200WN600238028 inch80001600202500WN7003000Above cutter suction dredger model let you reference . we can do and customized all dredging machinery equipment according to your requirements.11. Customoer feedback:
20inch Water Flow 4500m3 Cutter Suction Dredger with Anchor Boom
12.Why choose Set sail cutter suction dredger:            So far . our factory have received more than 100 country customers from the worldwide . we have won the recognition more and more customers with the high -quality product and enthusiastic service . Set sail factory expect you join in our huge family.

 20inch Water Flow 4500m3 Cutter Suction Dredger with Anchor Boom14. Factory certification :
