Factory Direct Supply Iron Ore Washing Machine for Sale
Gongyi Hengchang Metallurgical Building Material Equipments Plant- Type：Wheel Sand Washer
- Capacity：8-40 T,H
- Water Consumption：10-80t,h
- Speed of Screw：Wheel Sand Washer
- Motor Type：AC Motor
- Motor Power：4KW
Base Info
- Model NO.：GXS
- Certification：ISO, CE
- Rotation Speed：1-2 r,min
- Wheel Bucket Diameter：2000mm
- Screw Diameter：Wheel Sand Washer
- Name：Factory Direct Supply Iron Ore Washing Machine for
- Keywords：Iron Ore Washing Equipment
- Application：Stone
- Market：Europe
- Installation：Engineers Guide
- Motor：Chinese Famous Brand
- Usage：River Sand
- After Sale Service：Timely Installation
- Quality：Top
- Test&Installation：Professional Engineer Assigned
- Transport Package：Wooden Case, Standard Container
- Specification：GXS
- Trademark：hengchang
- Origin：China
- HS Code：8474100000
- Production Capacity：10 Set,Day
Description
Basic Info.
Model NO. GXS Certification ISO, CE Rotation Speed 1-2 r/min Wheel Bucket Diameter 2000mm Screw Diameter Wheel Sand Washer Name Factory Direct Supply Iron Ore Washing Machine for Keywords Iron Ore Washing Equipment Application Stone Market Europe Installation Engineers Guide Motor Chinese Famous Brand Usage River Sand After Sale Service Timely Installation Quality Top Test&Installation Professional Engineer Assigned Transport Package Wooden Case, Standard Container Specification GXS Trademark hengchang Origin China HS Code 8474100000 Production Capacity 10 Set/DayProduct Description
1.Introduction Of factory direct supply iron ore washing machine for sale
GongYi Professional Wheel River Sand Washer For Sale is used to remove the dust in sand. Sand washer aims at improving the quality of sand. The materials include the required gravel in building-site, gravel factories, hydropower station and concrete dam site, post and electric pole factory, casting-70 sand, glass factory's quartz sand and refilling pressure sand.Bucket Wheel Sand washing machine is widely used for cleaning materials in the following industries: quarry, minerals, building materials, transportation, chemical industry, water conservancy and hydropower, cement mixture station. So we design this machine ,which is mainly used for washing , selecting dewatering construction materials and sand materials.
2.Feature Of factory direct supply iron ore washing machine for sale
1. There is little loss for medium-sized or fine sand and stone powder.
2. There is no wearing parts except the screen mesh.
3. The mechanical failure ratio is much lower than Spiral Sand Washer.
4. It has a longer working life and lower maintenance frequency.
3.Working Principle Of factory direct supply iron ore washing machine for sale
1. A kind of sand washing appliance fit with the sand maker
2. It can wash away micro amount of stone powder and impurity from the mixed sand made by the sand maker to improve the quality of the sand
3. Impelled by generator and redactor drives the impeller to rotate in circles continuously in the water tank and then to make the sandstones and slag particles mixed, inverted and washed in the tank
4. Discharged after dehydration of the materials in the impeller.
4.Technical Parameters of factory direct supply iron ore washing machine for sale
| Model | Wheel Dia (mm) | Capacity (t/h) | Sand return Capacity(t/h) | Rotate Speed (r/min) | Power (kw) | Weight (kg) |
| GXS2010 | 2000 | 8-40 | 3-8 | 1-2 | 4 | 2000 |
| GXS2612 | 2600 | 20-100 | 5-15 | 1-2 | 5.5 | 3500 |
| GXS2814 | 2800 | 30-150 | 8-20 | 0.8-1.5 | 11 | 5200 |
| GXS3014 | 3000 | 50-200 | 10-30 | 0.8-1.5 | 15 | 7800 |
| GXS3214 | 3200 | 100-280 | 15-40 | 0.8-1.5 | 15 | 8800 |
| GXS3616 | 3600 | 130-460 | 30-60 | 0.8-1.5 | 18.5 | 14200 |
