Gravity Gold Concentrating Jig Machine for Fine Gold Separation
Ganzhou Gelin Mining Machinery Co., Ltd.- Type：Gravity Separator
- Voltage：380V
- Weight：1T
- Material：Steel
- Certification：ISO9001:2008, CE
- Energy Saving：Energy Saving
Base Info
- Model NO.：Jig machine
- Warranty：2 Years
- Color：Customized
- Customized：Customized
- Condition：New
- After-sales Service：Engineer Guidance,Video Guidance
- Usage：Gold Diamond Mining Wash & Separation
- Installation：Engineers Come to Mining Site Installation
- Transport Package：Nude , Export Packing Standard
- Trademark：GELIN
- Origin：China
- Production Capacity：1300sets Per Month
Description
ModelChamber Maximum
Feeding
size(mm) Water
added
m3/t Pressure
of water
Mpa Capacity
t/h Motor
power
kw Dimension
mm Weight
kg shape area(m2) JT0.57-1 Ladder 0.57 6 1-3 >=0.5 1-2.5 1.5 1550x780x1530 610 JT1-1 Ladder 1.04 10 1-3 2-4 2.2 2270x1110x1890 900 JT1.5-2 Rect 1.53 10 1-2 3-8 3 3200x1550x2050 1520 JT2-2 Rect 2.28 10 1-3 4-8 3 3225x1550x2050 1640 JT3-1 Ladder 3.3 10 1-3 6-10 5.5 3180x2000x2600 3260 JT4-2 Rect 4.33 30 1-3 10-15 7.5 3600x1850x2600 4600 JT5-2 Ladder 4.86 10 1-3 10-15 7.5 3600x2000x2600 4500 JT1.5-2S Rect 1.53 30 1-3 3-8 1.5x2 3200x1550x2050 1590 JT2-2S Rect 2.28 30 1-3 4-8 3x2 3225x1550x2050 1700 JT3-2S Rect 3 30 1-3 6-15 5.5x2 3560x2030x2600 3260 JT4-2S Rect 4.33 30 1-3 10-20 4x2 3600x1850x2600 4660 JT5-2S Ladder 4.86 30 1-3 10-20 5.5x2 3600x2000x2600 4700 JT6-3S Rect 6 30 1-3 15-30 7.5x2 4600x2000x2600 5900
2). Hydraulic Radial Jig
Hydraulic radial jig has been widely used as roughing separation equipment to select ore such as alluvial gold, tin, diamond, tungsten, manganese and hematite. Hydraulic radial jig is developed from circular jig. It's composed of two parts: drive and tank. The drive is mechanical hydraulic type, the power is provided by motor through the transmission mechanism let the output shaft of the gear reducer drives the cam rotation, the cam pushes the piston of each master cylinder make periodic reciprocating motion, which converts electrical energy into mechanical energy and then into hydraulic energy.
50-85Feeding size
(mm) <25<> Make-up water
(m3/t) 1-3m3/ton of ore Make-up water pressure
(MPa) ≥0.10 Capacity
(t/h) 50-75 66-100 78-125 100-150 116-175 132-197 150-200 166-245 182-270 200-300 Driving motor
(Kw) 5.5 7.5 7.5 7.5 11 11 11 15 15 22 hydraulic power unit
(Kw) 0.55 Weight
(kg) 6000 8000 10000 12500 14200 15800 17500 18000 19200 21000
4.Application
5.Packing&Delivery
6.About Us
Ganzhou Gelin Mining Machinery Company Limited is an expert manufacturing mining machines in China. Our company is located in the Industrial Zone of Shicheng County, Jiangxi Province.
Our distinctive products include Shaking table, Jig, Spiral separator, Gold concentrator, Ball mill, Jaw crusher, flotation, magnetic separator, Feeder, Classifier, ore washing machine and lab equipment etc. Our machines are popular in separating gold, copper, manganese, chrome, tungsten, tin, nickel, iron, titanium, lead, zinc, tantalum and some non-ferrous metals like quart, zircon, barite, etc.
Our products are sold to more than 28 provinces/cities in China and are exported to Russia, Africa, India, the Middle East, the Philippines, Mongolia, Sudan, Kazakhstan, Brazil, America, Canada and Australia. We have won high reputations from all of our clients for our machines and services.
Besides the above mentioned products, we can also design and manufacture many kinds of special mining machines and automatic processing lines according to the requests of customers. If you are in need of detailed information, please inform us. We will provide you with total solutions according to your specific requirements in time.
7.GELIN Services
--- PRE-SALE SERVICE ---
1.Based on clients' request and budget, GELIN experts will strictly make efficient, reliable solutions accordingly;
2.Mine sample testing is available, we welcome the customer send the sample to you for testing by courier, or, the customer take the sample to our factory for testing;
3. Design and provide the complete processing flowchart;
4. Design & manufacturer products according to clients' demands.
--- AFTER-SALE SERVICE ---
1.Pre-check and test the products before delivery;
2.Deliver the whole plant design for our clients which including infrastructure, electrical system and pipeline system design;
3.Trace the status of the shipping until the products received;
4.Prepare required documents to let clients pass custom clearance;
5.Dispatch experts to carry out below service on site:
1) Installation & debug of the machinery
2) Train the first-line operators & technical personnel
3) Carry out any other service clients may need
6. Provide technical exchanging & spare parts for life-long term
--- ONE STOP SOLUTION ---
1.Starting by running the mineral beneficiation experiment. To provide our clients with the best solution accordingly;
2.Besides supply the flowchart design & equipment, we also provide the infrastructure design; Electrical & pipeline system design, etc. To help our clients complete the design of the whole plant;
3.After the installation, debugging of the equipment, the official production will also be guiding by our experienced engineers on site, to guarantee the output minerals perfectly meet your demands.
8.Certificate
9.Customer Visiting
10.FAQ
Q: How big is your factory?
A: In tolal 6 work shops,17,000m², office 2500 m², 110 workers.Q: What Information should customers give to us in order to let we provide you with efficient & suitable quotation and assistance.
Q: Can we send the mineral samples to your company, let your company run the ore-dressing experiments test for us?
A: Yes, we can run the ore-dressing experiments for our customers. After the test, we will based on the results to give you the reasonable flowchart, suitable solution and equipments selection. etc.Q: How long is the warrenty of your equipments? Does your company supply the spare parts?
Feeding
size(mm)
added
m3/t
of water
Mpa
t/h
power
kw
mm
kg
2). Hydraulic Radial Jig
Hydraulic radial jig has been widely used as roughing separation equipment to select ore such as alluvial gold, tin, diamond, tungsten, manganese and hematite. Hydraulic radial jig is developed from circular jig. It's composed of two parts: drive and tank. The drive is mechanical hydraulic type, the power is provided by motor through the transmission mechanism let the output shaft of the gear reducer drives the cam rotation, the cam pushes the piston of each master cylinder make periodic reciprocating motion, which converts electrical energy into mechanical energy and then into hydraulic energy.
50-85
(mm)
(m3/t)
(MPa)
(t/h)
(Kw)
(Kw)
(kg)
4.Application
5.Packing&Delivery
6.About Us
Ganzhou Gelin Mining Machinery Company Limited is an expert manufacturing mining machines in China. Our company is located in the Industrial Zone of Shicheng County, Jiangxi Province.
Our distinctive products include Shaking table, Jig, Spiral separator, Gold concentrator, Ball mill, Jaw crusher, flotation, magnetic separator, Feeder, Classifier, ore washing machine and lab equipment etc. Our machines are popular in separating gold, copper, manganese, chrome, tungsten, tin, nickel, iron, titanium, lead, zinc, tantalum and some non-ferrous metals like quart, zircon, barite, etc.
Our products are sold to more than 28 provinces/cities in China and are exported to Russia, Africa, India, the Middle East, the Philippines, Mongolia, Sudan, Kazakhstan, Brazil, America, Canada and Australia. We have won high reputations from all of our clients for our machines and services.
Besides the above mentioned products, we can also design and manufacture many kinds of special mining machines and automatic processing lines according to the requests of customers. If you are in need of detailed information, please inform us. We will provide you with total solutions according to your specific requirements in time.
7.GELIN Services
--- PRE-SALE SERVICE ---
1.Based on clients' request and budget, GELIN experts will strictly make efficient, reliable solutions accordingly;
2.Mine sample testing is available, we welcome the customer send the sample to you for testing by courier, or, the customer take the sample to our factory for testing;
3. Design and provide the complete processing flowchart;
4. Design & manufacturer products according to clients' demands.
--- AFTER-SALE SERVICE ---
1.Pre-check and test the products before delivery;
2.Deliver the whole plant design for our clients which including infrastructure, electrical system and pipeline system design;
3.Trace the status of the shipping until the products received;
4.Prepare required documents to let clients pass custom clearance;
5.Dispatch experts to carry out below service on site:
1) Installation & debug of the machinery
2) Train the first-line operators & technical personnel
3) Carry out any other service clients may need
6. Provide technical exchanging & spare parts for life-long term
--- ONE STOP SOLUTION ---
1.Starting by running the mineral beneficiation experiment. To provide our clients with the best solution accordingly;
2.Besides supply the flowchart design & equipment, we also provide the infrastructure design; Electrical & pipeline system design, etc. To help our clients complete the design of the whole plant;
3.After the installation, debugging of the equipment, the official production will also be guiding by our experienced engineers on site, to guarantee the output minerals perfectly meet your demands.
8.Certificate
9.Customer Visiting
10.FAQQ: How big is your factory?
A: In tolal 6 work shops,17,000m², office 2500 m², 110 workers.
Q: What Information should customers give to us in order to let we provide you with efficient & suitable quotation and assistance.
A:1). What type is the mining? Is it rock stone? or it is sand?
2). If rock stone,What is the general particle size(mm) of the raw ore?
3). What is the handling capacity(tons per hour) you plan to work with?
4).What is the elements of the raw ore? How much percent % of each minerals?
Q: Can we send the mineral samples to your company, let your company run the ore-dressing experiments test for us?A: Yes, we can run the ore-dressing experiments for our customers. After the test, we will based on the results to give you the reasonable flowchart, suitable solution and equipments selection. etc.
