• Model NO.：PEX250*1200
• Inlet Size：250×1300mm
• Condition：New
• Transport Package：Export Standard
• Trademark：KINGLINK
• Origin：China
• HS Code：8474209000
• Production Capacity：100

Basic Info.

Model NO. PEX250*1200 Inlet Size 250×1300mm Condition New Transport Package Export Standard Trademark KINGLINK Origin China HS Code 8474209000 Production Capacity 100

Product Description

Features

kinglink's jaw crusher is engineered for even the toughest mining applications thanks to its heavy-duty design. Characterized by an attention to detail in its design and manufacture, this machine is an excellent choice when you need high production and low total cost.

kinglink's crushers are of the single-toggle type with advanced features for optimized performance, easy maintenance, long life and a low cost per ton. These crushers feature a deep, symmetrical crushing chamber, easy settings adjustment, a large feed opening for its size, and an ideal nip angle that offers smooth material flow and high reduction efficiency.

Benefits

• Simple structure, easy maintenance;
• Stable performance, high capacity;
• Even final particles and high crushing ratio;
• Adopt advanced manufacturing technique and high-end materials;

 Easy to install

kinglink's Jaw crusher has a range of bolt-on options, including an on-board motor base, and guarding for the flywheel and drives made from specially developed composite materials, which makes the unit simple to install as a crusher only or as a complete module in a new or existing plant.

The most versatile primary crusher



Kinglink's Series jaw crushers are most commonly used as primary crushers, to make the first step of size reduction. In some cases the jaw crushers is used to produce final end product but in most cases the jaw crusher is used to prepare the feed for the secondary crusher in a crushing and screening process.

Specifications

PE SERIES
Model	Feed Oping      (mm)	Max Feeding       (mm)	Discharge Oping      (mm)	Capacity       (t/h)	REV (r/min)	Power      (kw)	Weigth      (t)
PE250×400	250×400	210	20-60	5-30	300	15	2.8
PE400×600	400×600	340	40-100	16-85	275	30	6.5
PE500×750	500×750	425	50-100	45-130	275	55	10.1
PE600×900	600×900	500	60-160	50-160	250	55-75	15.5
PE750×1060	750×1060	630	80-140	52-180	250	110	28
PE800×1060	800×1060	650	100-200	85-185	250	110	30
PE870×1060	870×1060	670	200-260	181-210	250	110	30.5
PE900×1200	900×1200	750	195-265	140-280	200	110-132	50
PE1000×1200	1000×1200	850	195-265	160-390	200	110-132	51
PE1200×1500	1200×1500	1020	150-300	300-780	180	160	100.9
PEX250×750	250×750	210	25-60	8-30	330	22	4.9
PEX250×1000	250×1000	210	25-60	16-68	330	30-37	6.5
PEX250×1200	250×1200	210	25-60	20-78	330	37	7.7
PEX300×1300	300×1300	250	20-90	20-118	330	55	11

 * Smaller closed side settings can be often used depending on application and production requirements. For a performance estimation for your specific application, please contact Kinglink.

The above figures represent through the crusher capacities, which are based on a feed material with an average specific gravity of 2.7 t/m3, a maximum feed size that will enter the crusher without bridging and material finer than the crushers closed side setting removed. The capacities may vary depending on the feeding method and on feed characteristics such as gradation, bulk density, moisture, clay content and crushability. Measurement of the crusher's closed side setting varies depending on the jaw profile that is being used and has an impact on the crusher's capacity and product gradation. The following factors will enhance crusher capacity and performance:

1. Proper selection of the jaws.

2. Proper feed gradation.

3. Controlled feed rate.

4. Sufficient feeder capacity and width.

5. Adequate crusher discharge area.

6. Discharge conveyor sized to convey maximum crusher capacity.




Please contact us for more information you may need
