Mini electric / underground scooptram / loader / scraper for mining with best price
JINAN FUCHENG INTERNATIONAL TRADE CO., LTD.- Type:Bucket Conveyor
- Material:Carbon Steel
- Certification:CE, ISO9001
- Energy Saving:Energy Saving
- Warranty:1 Year
- Color:any color available
Base Info
- Model NO.:FCYJ-0.75E
- Customized:customization available
- Condition:New
- Max. Traction:41KN
- Max. Shovel Force :39KN
- Payload Capacity:1500kg
- Motor power:37KW
- Running speed full load:0-8km,h
- Max. Bucket Height:3600mm
- Rated capacity:1500kg
- Gradeability:25%
- Cable length:100m
- Total Weight:6500KG
- Transport Package:Container Packaging
- Specification:0.75m3
- Trademark:FUCHENG
- Origin:China
- HS Code:84293090
- Production Capacity:350 Sets , Year
Description
Basic Info.
Model NO. FCYJ-0.75E Customized customization available Condition New Max. Traction 41KN Max. Shovel Force 39KN Payload Capacity 1500kg Motor power 37KW Running speed full load 0-8km/h Max. Bucket Height 3600mm Rated capacity 1500kg Gradeability 25% Cable length 100m Total Weight 6500KG Transport Package Container Packaging Specification 0.75m3 Trademark FUCHENG Origin China HS Code 84293090 Production Capacity 350 Sets / YearProduct Description
Mini electric / underground scooptram / loader / scraper for mining with best priceFeatures:
1. FCYJ-0.75E Underground Electric LHD adopts Ac 380V three-phase asynchronous motor, rubber tire, front and rear axle drive at the same time. With advantage of compact structure, flexible and convenient operation.
2. Adopts the advanced way of three-point suspension articulated, which changes the old models'layout form of oscillating axle.
3. It has overcome the defects of oscillating axle's high failure rate, maintenance troubles, hidden dangers, greatly reduced the investment of manpower and material resources.
4. Synchronous winding down device of cable was used, making the tractor shovel more flexible during running.
5. Suitable for mining and roadway drivage slag, the construction of the road and work place, material transportation and so on.
Main Technical Parameters:
Item | Parameters |
Heaped Bucket Capacity | 0.75m3 |
Rated Capacity | 1500kg |
Max. Traction | 41 KN |
Max. Shovel Force | 39KN |
Running Speed | 0-8km/h |
Grade ability | 16° |
Max .Discharge Height | 850mm |
Min. Turning Radius | 2350mm |
Max. Rotation Angle | ±36° |
Min. Ground Clearance | 195mm |
Rated Power | 37kw |
Max. Bucket Height | 3600mm |
Effective Cable Length | 100m |
Weight(include hydraulic oil) | 6.5T |
Dimensions | 5800*1250*1900mm |
Product show
Shipment of product
Company profile:
Jinan Fucheng Hydraulic Equipment Co., Ltd mainly manufactures and sells various models of mine trackless equipment including underground scooptram, mining truck, drilling jumbo and service vehicle, etc.
Our company has passed ISO quality management system certification and obtained European CE certificate. Fengcheng has independent import and export operation rights, selling hot within China market and successfully exporting to Mexico, Australia, Africa, South America and other countries.
Since established, FUCHENG has been adhering to the idea of "guaranteeing quality, building harmony and common development". Excellent product quality, professional consulting service and perfect after-sales system have created a good brand image winning customer praise from all over the world.
FAQ:
Q: Are you manufacturer or trading company ?
A: We are manufacturer.
Q: What is the Payment terms ?
A: Usually by TT or LC, other terms could be negotiated.
Q: What is the delivery time ?
A: Normally the lead time is 30 days after receipt of down payment or LC.
Q: What is the warranty of the products ?
A: 12 months calculated from the goods arriving at the destination port.
Q: Do you provide equipment operation training?
A: Yes. We supply remote free online service. Or if need, we can send professional engineers to the working site for equipment installation, adjustment, and operation training.
Q: Can you customize the products?
A: Yes,we can customize as per your requirement.
Q: Where is the products are used?
A: The products are used for engineering, tunnels and mines except coal mine.
