Mining Machinery

Complete Set Wet Grinding Ball Mill for Mining (900X3000)

Zhengzhou Zhongding Heavy Duty Machine Manufacturing Co., Ltd.
  • Type:Ball Mill
  • Motor Type:DC Motor
  • Motor Power:15-1000kw
  • Application:Refractory Material, Silicate, Building Material
  • Materials:Feldspare,Zinc Ore, Copper Ore, Gold Ore,Silica
  • Condition:New

Base Info

  • Model NO.:1200x2800,2400x3600,3600x4500
  • Flowchart:Provided
  • Installation&Training:Provided
  • Grinding Method:Wet or Dry
  • Origin:China
  • Production Capacity:1-200t,H

Description

ModelSpeed (r/min)Max. weight of balls (t)Input size (mm)Output size (mm)Power (kw)Capacity (t/h)Weight (t)Φ900×1800371.8≤150.075-0.89150.5-23.4Φ900×2100372.3≤150.075-0.418.50.4-23.9Φ900×3000353.85≤250.075-0.4301.1-2.57.78Φ1200×2400354.6≤250.075-0.4301.3-3.28.65Φ1200×2800355.4≤250.075-0.4371.5-3.710.02Φ1200×4500358.6≤250.075-0.4452.7-6.7914Φ1500×3000299≤250.047-0.4753.3-8.214.12Φ1500×35002910.5≤250.047-0.4753.3-8.515.64Φ1500×45002913.5≤250.047-0.4904.5-1220Φ1500×57002917≤250.047-0.41102.6-1421.5Φ1830×30002413.5≤250.047-0.41354-1528Φ1830×36002414≤250.047-0.41354-1529Φ1830×45002420≤250.047-0.41554-1932Φ1830×70002431.5≤250.047-0.42106-2237.5Φ2100×30002218≤250.047-0.42106.4-2840.79Φ2100×36002220≤250.047-0.42107-2842Φ2100×40002221.5≤250.047-0.42107.6-2843.45Φ2200×360021.725≤250.047-0.42455.2-3244Φ2200×700021.746≤250.047-0.438015-3863Φ2400×36002128≤250.047-0.43208-6047Φ2400×45002135≤250.047-0.43808.5-6070.5Φ2700×360020.740≤250.047-0.440012-8075.5Φ2700×450020.748≤250.047-0.445012-90102Φ3200×40001865≤250.047-0.480030-180137

Note: Any change of technical data shall not be advised additionally.
Complete Set Wet Grinding Ball Mill for Mining (900X3000)
Application:Complete Set Wet Grinding Ball Mill for Mining (900X3000)
Features:Complete Set Wet Grinding Ball Mill for Mining (900X3000)


Customer Case
Complete Set Wet Grinding Ball Mill for Mining (900X3000)

Mongolia Limestone Grinding Project

Input Size: 20mmOutput Size: 150meshCapacity: 50t/h

Equipment: Φ2100X2400 Ball Mill, Dust Collector, Ball Mill Spare Parts
