• Usage：Large Blocks Splitting
• Splitting Diameter：42-45mm
• Piston Stroke：90,220mm
• Splitting Time：10-15s
• Transport Package：Import&Export Standard Wooden Cases
• Specification：450*410*700MM
• Trademark：Yugong
• Origin：China
• HS Code：8467890000
• Production Capacity：500

Model

YG-250

YG-350

YG-450

Power

Diesel Power Pack

Diesel Power Pack

Changchai 6hp or 8hp

Hydraulic Power Unit

Pressure Adjustable 10-60Mpa

Splitter Length (mm)

1000

1100

1200

Wedge Length (mm)

250

350

450

Wedge Weight (kg)

30

36

43

Piston Stroke (mm)

90/220

90/220

90/220

Drilling Depth (mm)

>500

>700

>900

Drilling Diameter (mm)

42

50

55

Crack Width (mm)

10-20

10-20

10-20

Splitting Time (s)

10-15

10-15

10-15

Splitting Force (T)

800

900

1000

Hydraulic Stone Splitter is used to split rock, stone, wall and concrete construction,which is a kind of machine to crack the rock, and that mostly used for construction,
ore extraction, engineering construction etc.It is widely used in mineral mining, civil engineering construction, demolition of buildings, river dredging and so on.

Main Features

1. Safe. Static demolition, no noise and no dangers to workers.

2. Environmental. Splitting slowly and power, no pollution to the environment.

3. Economical. Cost-effective and high efficiency, consistently working without maintenance.

4. Precise. Splitter could be put in pre-drilled holes and split according to precise directions, shapes and sizes.

5. Convenient. Device with special design, pulley with wheels, wedge with handles, ease and convenient for worker to operate.








1. Packaging: 1)Wrapped by protective film;
                             2)Packed by standard import & export wooden cases or carton boxes.
2. Shipping:   By logistics; by automobile; by train; by shipping; by air etc.

Q1: Are you trading company or manufacturer?
A1: We are original equipment manufacturer.

Q2: How long is your delivery time?
A2: It is according to the model and quantity.
Generally it is 3-5 days if the machines are in stock.
It will be 15-30 days if you want to customize the machines.

Q3: Do you provide samples? Is it free or extra?
A3: Yes, we could offer you the sample machine.
But it's not free. You need to pay for the sample and the cost of freight.

Q4: What is your terms of payment?
A4: We accept T/T, Western Union, Money Gram, Paypal, Alibaba Escrow etc.
Payment<=USD 5000, 100% in advance.
Payment>=USD 5000, 30% T/T in advance, balance before shipment.
