Cutter Suction Dredging Machine (CSD 150)

Qingzhou Yongsheng Dredging Equipment Co., Ltd.
  • Type：Dredger
  • Certification：ISO 9001,CE,BV,Zc,CCS
  • Water Flow：500m3,H
  • Dredging Depth：8m
  • Engine：Weichai,Cummins,Jichai
  • Patent No. of Structure：Zl 2012 2 0301711.9

Base Info

  • Model NO.：CSD 150
  • Control System：PLC System
  • Pump：Warm Technology
  • Discharge Distance：800
  • Mining Object：Sand, Mud, Slurry, Silt, Slush, Sludge, Salt, Iron
  • Transport Package：Nude
  • Specification：CE, ISO9001, ZC, CCS, BV, Patent No.
  • Trademark：yongsheng dredger
  • Origin：Qingzhou City, Shandong Province, China
  • HS Code：89051000
  • Production Capacity：20 Sets

Description

No. Item Parameters
M Feet
1  Total Length
(with ladder raised)  		 15 49.2
2       Side pontoon    12 39.4
3 Hull Width 4.8 15.7
4 Hull Depth 0.8 2.6
5 Draft 0.8 2.6
6 Max. Dredging Depth 8 26
7 Max. Discharge Distance 800 2600
8 Water flow 500m3 per hour
9 Total dry weight of machine 30ton

2. Diesel Engine (2)

Item Main Engine Standby Generators
Made Steyr Marine Engine Weichai
Model 61546DC Generator set
Power 202kw 24kw
Amount 1 Set 1 Set
