Hydraulic Pump Diesel Engine 16 Inch Cutter Suction Dredger
Qingzhou Set Sail Dredging Equipment Machinery Co., Ltd.- Type：Cutter Suction Dredger
- Power Type：Diesel
- Cyclone Type：Hydrocyclone
- Slot Type：CTD
- Customized：Customized
- Condition：New
Base Info
- Model NO.：QHCSD-488
- Warranty：2year
- After-sales Service：Lifelong
- Total Length：16 Meter
- Main Engine Brand and Power：Cummins 582 Kw
- Auxiliary Engine Power：Cummins 224 Kw
- Generator Power：Cummins 30 Kw
- Maximum Dredging Depth：13 Meter
- Inner Pipe Diameter：400mm
- Water Flow：2500 Cubic Meter
- Capacity：500 Cubic Meter
- Discharge Distance：1500 Meter
- Cutter Head Diameter：1450mm
- Cutter Head Power：108kw
- Bottom Plate Thickness：10mm
- Side Plate Thickness：8mm
- Deck Plate Thickness：8mm
- Front Plate Thickness：14mm
- Transport Package：Canvas
- Specification：16 inch cutter suction dredger
- Trademark：Set Sail
- Origin：Qingzhou City Shandong Province China
- HS Code：8905100000
- Production Capacity：10000 Set,Year
Description
Cutter Suction Dredger is self-propelled or non self-
pro-pelled. portable cutter suction dredger.Hull can be
dis-mantled and re-assemble easily with box
structure.Equipped with horizontal shifting devices.
cutter ladder lifting devices. spud devices. deck crane
and so on.Widely used in sand-excavating.river
dredging. desilt-ing.Reclamation for channels and land
port construction, etc.
Mainly features:1 Cutter suction dredger is suitable for inland waterways. lakes. rives of dredging. 2 Standard design. allowing early delivery and low price. 3 Cutter suction dredger has advantages of high output. low cost and convenent rapare. 4 Completely assembled and fully tested before delivery. 5 Cutter suction dredger adopt hydeaulic system. this system is very steady. it isn't easy to appear failure. 6 Simple rapid assembly and dismantling. 7 Ready for operation on arrival at site. 8 Dredging pump adopt diesel engine to transmission.the power is stonger and steady. 9 Spare parts available from stock. 10 Transportable by road. rail or sea. 11 Reliable hydraulic system. 12 Efficient fuel consumption.
16 inch dredger image:
Detailed parts introduce :
16 inch dredger basic information :Dredger Loa 32.0m Hull Size(L*B*H) 19.0×7.5×2.0m Main pontoon(L*B*H) 13.8×3.5×2.0m Side Pontoon(L*B*H) 19.0×2.0×2.0m Structure Box-structure Main Engine Brand&Power Cummins 582kw/Jichai 540Kw Auxiliary enging power Cummins 224kw Harbour Generator Cummins 30kw/Jichai 30kw Total Power Cummins 836kw/Jichai 790kw Dredging Pump Warman Technology Discharge Pipr Inner Dia. 400mm Head 45m Max.Dredging Depth 13m Water Flow 2500m³/h Solid Sand Capacity 500m³/h Cutter head diameter 1450mm Cutter head power 108kw
Dredger at installation site :
Dredger packing and transportation :
Our service :1 offer the solution and design before the sale. 2 Inquiry and consulting support. 3 Sample testing support. 4 View our Factory. 5 Training how to instal the machine, training how to use the machine. 6 Engineers available to service machinery overseas.
Our customer:
Company overview:1 More than 25 years experience 2 More than 120 certificated engineers and technicians 3 Cooperated with famous ship design & research institute and Ocean University 4 Exported to more than 80 countries in all over the world
Question for customer:1 The capacity of the output per hour? 2 The max.dredging Depth ? 3 The max. discharge distance ?
