• Model NO.：ZS-GH-CP43
• HS Code：4016
• Production Capacity：500PC,Month

Basic Info.

Model NO. ZS-GH-CP43 HS Code 4016 Production Capacity 500PC/Month

Product Description

7" Well Cementation Cementing Top Plug

Our factory are proud to be a regular Grade 1 supplier for SINOPEC! So you can trust on our stable quality. We specialize in various cementing plugs, both standard type and customized type, what's more, our massive producing line allow us supply you cementing plugs with lowest costs.

Advantages:
The Cementing Plugs manufactured in out company include top plugs and bottom plugs.

These plugs offer the following advantages;
Special non-rotational device design allowing the plugs to drill out quickly;
Special materials designed for easy drill out with PDC bits;
High-heat and high-pressure
API certification approved

Introduction
The cementing plugs manufactuered in our company include top plug and bottom plug
1, Top and Bottom cementing pulg
2, Traditional and non-rotating type
3, High temperature and high pressure resistance

Description:
A rubber plug used to separate the cement slurry from other fluids, reducing contamination and maintaining predicatble slurry performance. Two types of cementing plug are typically used on a cementing operation. The bottom plug is launched ahead of the cement slurry to minimize contamination by fluids inside the casing prior to cementing. A diaphragm in the plug body reptures to allow the cement slurry to pass through after the plug reaches the landing collar.

The top plug has a solid body that provides positive indication of contact with the landing collar and bottom plug through an increase in pump pressure.

Technical Parameters:

Size,inch	O.D.,mm	Length,mm	Bottom Cementing Plug Rubber membrane burst pressure, MPa
114.3mm	114	210	1~2
127mm	127	210	1~2
139.7mm	140	220	1~2
168mm	168	230	1~2
177.8mm	178	230	1~2
244.5mm	240	260	1~2
273mm	270	300	1~2
339.4mm	340	350	1~2
457mm	473	400	2~3
508mm	508	400	2~3
