159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler Group

DEZHOU YILUN CONVEYING MACHINERY CO., LTD.
  • After-sales Service：24 Hourse Online After Sale
  • Warranty：One Year
  • Certification：ISO9001:2015
  • Standard：AISI, JIS, GB, GOST, ASTM, DIN
  • Surface Treatment：Polishing
  • Manufacturing Process：Welding

Base Info

  • Model NO.：159*530
  • Material：Carbon Steel
  • Color：Red, Black, Yellow, Grey etc
  • Certificate：BV
  • Diameter：50,60,76,89,102,108,114,127,133,140,159,165,178
  • Length：100-3500mm
  • Bearing：6204,6205,6305,6306,6307
  • Shaft Diameter：20-50mm
  • Slot：Slot End
  • Life Time：More Than 50000hours
  • Standards：GB, Cema, DIN, JIS, Etcs
  • Seal：Double Labyrinth Seal
  • Transport Package：Wooden Box
  • Specification：Q235B
  • Trademark：YILUN
  • Origin：Shandong, China
  • HS Code：84313900
  • Production Capacity：1500PCS,Day

Description

1PipeHigh precision ERW special pipe with small out of roundness. Material Q235 equal to Europe S235JR2ShaftHigh precision cold-drawn round bar, Material 45# equal to DIN C45.3BearingDeep groove ball bearing with clearance C3. Double Seal, Quality Grade P5Z34Bearing HouseCold drawn steel plate, material 08AL equal to DIN ST12/145Inner SealLip type seal, Material Nylon.6Labyrinth SealMain Seal System, Material is Nylon.7Lubricating Grease#2 Long lasting lubricating grease, working condition -40°c to 180°c8Surface TreatmentElectrostatic Powder Coating
2.Brife introduction for Yilun Conveyor roller1.Material: Steel,rubber
2.Bearing:6204,6205,6305,6306,6307,6308,6309,6310
3.Daimeter: Ø50-Ø219
4.Lenght:120mm-2200mm
5.Seal: double labyrinth seal
5.Workign life:30000-50000hours
6.Standards:GB,CEMA,JIS,DIN,AUSTRALIA
7.Color: mulit-color for choice159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler Group3.Advantages159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler Group159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler GroupThe pipe we choose is the high quality welding pipe,the roundness is The shaft we choose is high-precsion rond cold steel,the roundness is
lower 0.6mm,the straightnesss is 0.15%, the wall thickness tolerance 0.8, and the tolerance is only ±0.0065mm, make sure the bearing and
is ±0.1mm, the thickness from 2.5~6.0mm, diaeter is from 50~219mm. shaft match closely, the bearing move safely.
0.8,±0.1mm, the thickness from 2.5~6.0mm, diaeter is from 50~219mm.
The pipe is rust removal to increase paint adhesion.159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler Group159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler Group
Bearing housing is punched by the superipr steel sheet(SPHC), This bearing is the joint ventures, it is the roller special double
After that, we will use the housing circle machine to cut the outside seal, the bearing inner race have V-groove, grease is also the
of the housing, to make sure the high Concentricity of the roller and imported grease (Inject the grease into the both sides of the ball
the small runout. bearing).159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler Group159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler GroupThis seal is the national standard double labyrinth seal, 4 pieces We can print the brand for the customer requests, but need the
pom and 3 pieces stell seal.Injected the high quality No.2 lithium customer give us the authorization.
grease. it is water proof and dustproof,anti-corrosion,wear-resisting,ect...
 Diameter of TubeLength of TubeBearing TypeTube Wall Thicknessmminchmm (mm)63.52 1/2150-350062043.0-3.75763150-35006204 62053.0-4.0893 1/2150-35006204 62053.0-4.01024150-35006204 6205 63053.5-4.01084 1/4150-35006204 6205 6305 63063.5-4.01144 1/2150-35006204 6205 6305 63063.5-4.51275   150-35006204 6205 6305 63063.5-4.51335 1/4150-35006205 6206 6207 6305 63063.5-4.51405 1/2150-35006205 6206 6207 6305 63063.5-4.51526   150-35006205 6206 6207 6305 6306 6307 63084.0-4.51596 1/4150-35006205 6206 6207 6305 6306 6307 63084.0-4.51656 1/2150-35006207 6305 6306 6307 63084.5-6.0177.87   150-35006207 6306 6307 6308 63094.5-6.0190.57 1/2150-35006207 6306 6307 6308 63094.5-6.01947 5/8150-35006207 6307 6308 6309 63104.5-6.02198 5/8150-35006308 6309 63104.5-6.0
4.Technical quality team
159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler Group
4.Packing & Shipping
we can provide different kinds of packing for the customer.
Wooden box and wooden pallet packing for your choice.
159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler Group5.Certificate
159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler Group5.Customer visiting and the exhibitions
159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler Group6.After sale service
We provide the customer best after sale services, and we solve the problems any time.
159mm Dia Steel Tube Heavy Duty Trough Roller Conveyor Idler Group7.Company introduction
1.)Dezhou Yilun conveying Machinery Co.,Ltd was founded in 2005.
2.)It's registered capital is 11.68million CNY and It is private joint-stock enterprise. Our main products are cnoveyor roller,idler,frame, pulley,belt and belt conveyor system for TD75 ,DTII,DTIIA,CEMA ects.
3.)we has large lathes, numerical control, double pressing machine, double welding machine, double boring lathe, milling machine, sawing machine and so on. The products have gained various patents. We can produce more than one thousand rollers and ten pulleys per day.
4.)We have the professionalQC dept. to keep the good quality before the goods sent out.
The products are sold to Middle East,Africa ,Australia,Europe,Southeast Asia,Russia and some other countries and regions. We will Strengthen the inner management and improve our products' quality constantly.
We will offer the best products for customers from the beginning to the end.

8.FAQ

1.Q: Your bearing type and brand usually use?
A:Large clearance C3 ZZ 2RStype deep ball bearing withSRB, and according to customer's requirements.

2.Q: How is your Payment Term?
A: T/T or L/C. Another payment term we can also discuss.

3.Q: Can you customize it?
A: We support customization according to your request.

4.Q: What's the MOQ?
A: 50 piece.

5.Q: What's the production capacity of your conveyor roller?
1500 pcs/day.

6.Q: What's your roller's lifetime?
Our rollers have a long lifetime with good performance and usually
make sure 30000 to 50000 hours under the normal site and operation.
