• Model NO.：DGCSD500
• Capacity：3500 Cbm,H
• Transport Package：Bulk Vessel
• Trademark：Dragon
• Origin：China
• HS Code：8905100000

Basic Info.

Model NO. DGCSD500 Capacity 3500 Cbm/H Transport Package Bulk Vessel Trademark Dragon Origin China HS Code 8905100000

Product Description

Introduction
DRAGON dredgers are known for their high efficiency, robust construction, unbeatable economies of scale and lower operating costs, with the reliability and ease of use for operating in all conditions. The latest series is designed to be even more sustainable, safer and efficient.
Their modular construction means they are easy to transport and can be commissioned quickly at dredging site. They can be delivered with a complete and integrated package of equipment and service, including work boats, spare parts, training, dredging consultancy and maintenance support.

Strong and high efficiency Pump


During manufacturing, our quality control department keep high frequency quality check in every details.


All the dredger system will be tested in the subsupplier's factory and in our factory.



The modular design makes the transportation easier and faster. It can be transported by truck or railways.

Specification

Model	DGCSD200	DGCSD250	DGCSD300	DGCSD400	DGCSD500	DGCSD600
Overall Dimension	22 x 5.0 x 1.5m	25 x 5.2 x 1.6m	27 x 5.4 x 1.6m	32 x 6.4 x 1.8m	39 x 7.8 x 2.2m	44 x 8.8 x 2.4m
Max. Capacity	600 m3/hr	900 m3/hr	1300 m3/hr	2100 m3/hr	3500 m3/hr	5000 m3/hr
Max. Dredging Depth	8 m	10 m	12 m	15 m	16 m	18 m
Max. Discharge Distance	500 m	800 m	1000 m	1500 m	2000 m	3000 m
Installed Power	200 kw	336 kw	559 kw	895 kw	1231 kw	2446 kw
Discharge Pipe Diameter	200 mm	250 mm	300 mm	400 mm	500 mm	600 mm
Cutter Diameter	800 mm	1100 mm	1100 mm	1400 mm	1700 mm	2400 mm
Cutter Power	30 kw	43kw	60 kw	98 kw m	165 kw	220 kw
Ladder Winch Capacity	30 kn	40 kn	50 kn	80 kn	100 kn	160 kn
Swing Winch Capacity	30 kn	40 kn	50 kn	60 kn	80 kn	120 kn
Operation	Hydraulic and PLC control	Hydraulic and PLC control	Hydraulic and PLC control	Hydraulic and PLC control	Hydraulic and PLC control	Hydraulic and PLC control
Max. Fuel Consumption	35-40 l/hr	60-70 l/hr	90-100 l/hr	155-170 l/hr	210-230 l/hr	400-430 l/hr
Weight	35 t	50 t	62 t	98 t	153 t	220 t

After-sale Service
DRAGON customers rely on the unrivalled level of commitment that is offered to them through dedicated and comprehensive life-cycle support services. These help to maximise the equipment's availability and the return on investment, and therefore reduces the total cost of ownership. The cycle can be entered at any of its five integrated stages.

BTW, we are able to suppy a complete set of products, floaters, HDPE Pipes, Steel Pipes together with dredgers.
