• Model NO.：YQJ
• Installation：Engineer Guide
• Price：Negotiation
• MOQ：1 Set
• Certification：Ce,ISO9001,SGS,BV
• Application：Coal
• Market：Europe
• Roller Material：65 Mn
• Pressure Form：Constant Wedge Pressure
• Transport Package：Container
• Specification：QYQ
• Trademark：Hengchang
• Origin：China
• HS Code：8463900010
• Production Capacity：100 Set,Day

Basic Info.

Model NO. YQJ Installation Engineer Guide Price Negotiation MOQ 1 Set Certification Ce,ISO9001,SGS,BV Application Coal Market Europe Roller Material 65 Mn Pressure Form Constant Wedge Pressure Transport Package Container Specification QYQ Trademark Hengchang Origin China HS Code 8463900010 Production Capacity 100 Set/Day

Product Description

1.Product Application of Coconut Powder Briquette Machine With Good Quality

Four-roller Twice Pressure Briqutte Machine is mainly used for civil and industrial coal production, superior technical performance of the equipment, compact structure, reasonable assembly process, forming rolls made of special alloy materials, long life, but also solve the coal production ubiquitous molding pressure is low, the intensity of small balls and other issues, is the ideal equipment for briquette production.


2.Working principle of Coconut Powder Briquette Machine With Good Quality

Four roller machine works is two pairs of roller in the form of pipeline materials on the pre-suppression, for the finished ball to lay a solid foundation for quality. The pressure ball machine is through the reducer will be transmitted to the two pressure roller at the same time, and the two roller rotation, in the two roller rotation, the material naturally into the pressure roller on the ball, with the pressure roller The pressure of the material to bear the pressure becomes small, when the material turns to the two rollers of the line contact point, the material to withstand the pressure has reached its peak, and then through the main roller feeding and secondary pressure, so that the pressure of the material into Times to increase, squeeze out the finished product more solid.

 3.Technical Parameters of Coconut Powder Briquette Machine With Good Quality


Model	Roller Dia.r (mm)	Roller Width (mm)	Roller Material	Shaft Speed(r/min)	Reducer Model	Pressure Form	Motor Power (kw)	Capacity (t/h)
YQJ-290	290	200	65Mn	18	ZQ350	Constant Wedge Pressure	5.5	1-2
YQJ-360	360	250	65Mn	18	ZQ400	Constant Wedge Pressure	7.5	2-4
YQJ-400	400	250	65Mn	18	ZQ400	Constant Wedge Pressure	11	4-6
YQJ-500	500	300	65Mn	13	ZQ500	Constant Wedge Pressure	18.5	6-10
YQJ-650	650	336	65Mn	13	ZQ650	Constant Wedge Pressure	30	10-15

4.Main Features of Coconut Powder Briquette Machine With Good Quality

1. Good price with CE ISO certificate.

2. Different type:roller type,hydraulic type, high pressure type coal briquette machine

3. Strong structure,high briquetting ratio because the briquette machine excellent design,it can be the single machine or whole production line.

4. Since the system out of the briquettes have desulfurization, reducing sulfur emissions, it is also conducive to environmental protection, the State Environmental Protection Agency emission reduction industry, civilian machinery

5. The device is superior technical performance, compact structure, reasonable assembly process, forming rolls made of special 65Mn, 9Cr2Mo, alloy materials, long life


Finished product



5.Our service

1) Installation and guidance
When the machine arrives at your company, we will dispatch our technicians to your company to guide the installation and commissioning at site. User should pay for the following fees air tickets, boarding and lodging and traffic in client's factory.

(2)Technical training
We provide free technical training service to your stuff. Training content contains the main work principle of machine, operating regulations, maintenance methods and steps, safety, etc.

(3)Warranty:
Three guarantees of our product quality, warranty for one year (not include man-made damaged). We will maintain the machine for free for the quality problem. If the damage is caused by your improperly operation, the cost of the maintenance burden by you. we also provide you the  life-long follow-up service.



6.Our copmany

Gongyi Hengchang Metallurgy Building Material Equipments plant is a professional manufacturer specializing in the production of mineral beneficiation equipments, sand and stone crushing equipments, briquetting equipments, coal preparation equipments, drying and calcining equ
ipments, cement plant equipments and compound fertilizer equipments.



7.FAQ

Q:Hi, are you mining machinery manufacturer?

A:Yes, we can also provide amples test, mine design, equipment manufacture, after-sale service, etc.

Q:which country have your products been exported?

A:Many country, such as India, Ethiopia and so on. And our company has agencies in Zimbabwe, Sudan and Tanzania.

Q:Can you do mineral processing test?

A:Yes, not only can do it in your country, also can back to our company
