Hualong Mine Quarrying Machine Mountain Stone Sawing Machine for Marble Granite Travertine

Fujian Province Hualong Machinery Co., Ltd.
  • Gross Power:117.2kw
  • Blade Diameter:3000mm

Base Info

  • Model NO.:2QYK-3800
  • Max. Cutting Size:1250mm
  • Power of Main Moto:55X2kw
  • Power of Pump Motor:3.5kw
  • Power of Stroke Motor:2.2kw
  • Power of Lengthwise Railway Switch Motor:0.75X2kw
  • Gross Weight:7000-8500kg
  • Cutting Width:1360-1860,1800-2300,2200-2700,2700-3200mm
  • Transport Package:Plastic Film Packing
  • Specification:3500x2200x3200mm
  • Trademark:Hualong
  • Origin:Putian, Fujian, China
  • HS Code:84303900
  • Production Capacity:50PCS,Month
  • Package size per unit product:350.00cm * 220.00cm * 320.00cm
  • Gross weight per unit product:7000.000kg

Description

Basic Info.

Model NO. 2QYK-3800 Max. Cutting Size 1250mm Power of Main Moto 55X2kw Power of Pump Motor 3.5kw Power of Stroke Motor 2.2kw Power of Lengthwise Railway Switch Motor 0.75X2kw Gross Weight 7000-8500kg Cutting Width 1360-1860/1800-2300/2200-2700/2700-3200mm Transport Package Plastic Film Packing Specification 3500x2200x3200mm Trademark Hualong Origin Putian, Fujian, China HS Code 84303900 Production Capacity 50PCS/Month

Packaging & Delivery

Package size per unit product 350.00cm * 220.00cm * 320.00cm Gross weight per unit product 7000.000kg

Product Description

2QYK Series Double Stonecutter Machine is with double blades, suitable for granite, marble and stone quarries cutting in general. The principle axis lifting adopt four cylinders as the guide rail, combining with the oil cylinder hydraulic to control the lifting.

The unique features and advantages are:

 -- Four-wheel drive power;

 -- No need triangle belt, change the traditional belt elastic problem;

 --Faster, more energy saving, more stable, more safe;

-- Small gap, Wear less, Vibration-free;

-- Greatly prelong the use life of the blades;

--To protect environment, save mining cost, increase output and recover;

-- The cylinder guide rail adopt fully enclosed protection to ensure the guide rail not to be contaminated, combinating with the unique lubrication systerm to greatly improve the use life of the machine and mining efficiency, and greatly deduct the maintenance and repair cost.

The 2QYK  series mining quarrying machine cutting width, depth can be customize according to customer requirements. Such as the diameter of blades can do  φ3000, φ3300, φ3500, φ4000/φ4200, φ5000

Hualong Brand's quarry machine is the oldest brand in China more than 20 years.  We are the leading force in the development of stone mining machinery and equipment. Products of research and development has changed the traditional extensive mining methods of mining stone, improved the utilization of natural resources of stone, reduced the pollution of the environment and the labor intensity of workers.
With so many years' development and improvment, Hualong quarry machine is well known both domestic and abroad becasue of its steady quality and after sell service.

Hualong Mine Quarrying Machine Mountain Stone Sawing Machine for Marble Granite Travertine

Hualong Mine Quarrying Machine Mountain Stone Sawing Machine for Marble Granite Travertine

Hualong Mine Quarrying Machine Mountain Stone Sawing Machine for Marble Granite Travertine


Hualong Mine Quarrying Machine Mountain Stone Sawing Machine for Marble Granite Travertine

Detailed Images

Hualong Mine Quarrying Machine Mountain Stone Sawing Machine for Marble Granite Travertine

3 rollers physicaly design

Double main motors drive the double blades more smooth,more steady and more efficiently.

Hualong Mine Quarrying Machine Mountain Stone Sawing Machine for Marble Granite Travertine

Advantage of Blade with Cut hole design

1) Reduce dead weight, reduce load, reduce power loss by about 40%.

2) Both convenient with cooling water into the joint, enhance the cooling effect of the saw blade deformation, and better will be the joint sand discharge, but also can release the stress generated in the use, more resistant to deformation, longer life

Hualong Mine Quarrying Machine Mountain Stone Sawing Machine for Marble Granite Travertine

Power Connection & Operation Panel

Brand: Schneider, SINEE, C-Lin, TENGEN
Original: China
Quality certificated by CE

Hualong Mine Quarrying Machine Mountain Stone Sawing Machine for Marble Granite Travertine

Main motor

Name: Three-phase asymchronous motor
Brand: ND
Efficiency: 92.5%
Original: China


Domestic famous engines, strong driving force, good efficiency, high economic benefits.
