• Model NO.：ZS-GH-RC09
• Factory Visit：Yes
• Technical Support：Yes
• Materials：Aluminium, Aluminium Alloy
• Size：4 1,2"-20"
• Transport Package：Cartons and Wood Case Packaging
• Specification：API
• Trademark：ZS
• Origin：Henan, China
• HS Code：7609
• Production Capacity：10000PC,Month

Basic Info.

Model NO. ZS-GH-RC09 Factory Visit Yes Technical Support Yes Materials Aluminium, Aluminium Alloy Size 4 1/2"-20" Transport Package Cartons and Wood Case Packaging Specification API Trademark ZS Origin Henan, China HS Code 7609 Production Capacity 10000PC/Month

Product Description

Slip-on Solid Straight Blade Rigid Centralizer

Specifications
Rigid Straight Blade solid centralizer
1. Size"4-1/2"-20"
2. API 10D Certificate
3. Soild Body Rigid Centralizer

Spiral Rigid Centralizer:

1. Description
Centralizers are an integral part of the cementing process. They provide the mechanism that centers the casing in the hole and allows uniform cement flow around the casing to help protect it at all points. Several styles of centralizers are available for matching different well specifications and hole sizes, including turbulence generating designs that help clean the annulus and distribute the cement more evenly and uniformly.

All models offer sufficient clearance for fluid passage and are extra effective in centering the casing, even in highly deviated holes and improve cement flow by reducing the effects of channeling.

2. Features
1. Spiral vane;
2. With the shape of stream-lined, enables casing run easily in wellbore.
3. Straight vane and spiral vane are available.
4. The material can be cast / Carbon steel or cast aluminum.

Technical Parameters:

Model	Style	Max OD, mm	ID, mm	Length, mm
ZSGF-4 1/2"*6"	I, II, III	145	116.5	200
ZSGF-5"*6"	I, II, III	145	129	200
ZSGF-5 1/2"*8 1/2"	I, II, III	205-210	142	200/300
ZSGF-6 5/8"*8 1/2"	I, II, III	205-210	171	200/300
ZSGF-7"*8 1/2"	I, II, III	205-210	181	200/300
ZSGF-7"*9 1/2"	I, II, III	225-235	181	200/300
ZSGF-7"*9 5/8"	I, II, III	225-235	181	200/300
ZSGF-9 5/8"*12 1/4"	I, II, III	300-305	248	200
ZSGF-13 3/8"*17 1/2"	I, II, III	430-435	346	200

Note: ZSGF series rigid casing centralizer is divided into straight strip type (Type I), spiral type (Type II) and roller type (Type III).
