• Energy Saving：Energy Saving
• Warranty：2 Years
• Color：Multi Color
• Customized：Customized
• Condition：New
• After-sales Service：2year
• Applicable Industries：Crushing Plant, Mineral Processing Plant etc
• Layer：1-4
• Advantage：Long Working Life and Large Capacity
• Transport Package：Nude&Wooden Box
• Specification：30-1000tph
• Trademark：sinonine
• Origin：China
• HS Code：8474100000
• Production Capacity：150set,Year

Basic Info.

Energy Saving Energy Saving Warranty 2 Years Color Multi Color Customized Customized Condition New After-sales Service 2year Applicable Industries Crushing Plant, Mineral Processing Plant etc Layer 1-4 Advantage Long Working Life and Large Capacity Transport Package Nude&Wooden Box Specification 30-1000tph Trademark sinonine Origin China HS Code 8474100000 Production Capacity 150set/Year

Product Description

YK Series circular vibrating screens are designed by our company through absorbing Germany advanced technology. It is equipped with adjustable amplitude, long drip line, multi-layered screening with distinct griller and high efficiency. It is particular designed for separating materials into various sizes for further processing in Crusher and widely used in building material,mineral,chemistry, etc.

Features of YK vibrating screen
1.Use the unique eccentric structure to produce powerful vibrating force.
2.The beam and case of screen are connected with high strength bolts without welding.
3.Simple structure and easy maintenance.
4.Adopting tire coupling and soft connection makes operation smooth.
5.High screen efficiency, great capacity and longer service life.

Working principle of YK vibrating screen
The motor makes the exciter rotating speedily through the V-belt. Besides, the great centrifugal force produced by rotating eccentric block makes the sieve box do circular motion of some amplitude, together with the impulse transmitted through sieve box on the slope surface, which makes the materials on the screen surface successively tossed forward. Thus the classification is achieved in the process of thrown-up as materials with smaller size than the mesh is falling through.

Specification of YK vibrating screen

Model	Layer	Sieve area (m2)	Mesh size (mm)	Max feed size (mm)	Capacity (t/h)	Power (Kw)	Sieve size (mm)
YK1236	1	4.3	3-100	300	20-150	5.5	1180×3550
2YK1236	2	4.3	3-100	300	20-150	5.5	1180×3550
3YK1236	3	4.3	3-100	300	20-150	7.5	1180×3550
4YK1236	4	4.3	3-100	300	20-150	11	1180×3550
YK1548	1	7.2	3-100	400	20-150	11	1480×4750
2YK1548	2	7.2	3-100	400	20-150	15	1480×4750
3YK1548	3	7.2	3-100	400	20-150	15	1480×4750
4YK1548	4	7.2	3-100	200	20-150	18.5	1480×4750
YK1848	1	8.6	3-100	400	32-350	15	1780×5950
2YK1848	2	8.6	3-100	400	32-350	18.5	1780×5950
3YK1848	3	8.6	3-100	400	32-350	18.5	1780×5950
4YK1848	4	8.6	3-100	400	32-350	22	1780×5950
YK1860	1	10.8	3-100	400	32-350	15	1780×5950
2YK1860	2	10.8	3-100	400	32-350	18.5	1780×5950
3YK1860	3	10.8	3-100	400	32-350	22	1780×5950
4YK1860	4	10.8	3-100	400	32-350	22	1780×5950
YK2160	1	12.6	3-100	400	66-720	18.5	2080×5950
2YK2160	2	12.6	3-100	400	66-720	22	2080×5950
3YK2160	3	12.6	3-100	400	66-720	30	2080×5950
4YK2160	4	12.6	3-100	400	66-720	30	2080×5950
YK2460	1	14.4	3-100	400	75-750	18.5	2080×5950
2YK2460	2	14.4	3-100	400	75-750	30	2380×5950
3YK2460	3	14.4	3-100	400	75-750	37	2380×5950
4YK2460	4	14.4	3-100	400	75-750	37	2380×5950
YK3060	1	18	3-100	400	200-900	30	2980x5950
2YK3060	2	18	3-100	400	200-900	37	2980x5950
3YK3060	3	18	3-100	400	200-900	45	2980x5950
4YK3060	4	18	3-100	400	200-900	45	2980x5950
