New mining electric underground wheel loaders from Chinese manufacturer
JINAN FUCHENG INTERNATIONAL TRADE CO., LTD.- Working Mode:Wheeled
- Ground Clearance:250mm
- Rated Capacity:3000kg
- Max. Bucket Height:3740mm
- Running speed:0-10km,h
- Steering Angle:33 degree
Base Info
- Model NO.:FCYJ-1.5E
- Gradeability:16 degree
- Weight:11600kg
- Max Shovel:73KN
- Max Traction:92KN
- Transport Package:Container Shipment
- Specification:1.5m3
- Trademark:FUCHENG
- Origin:Shandong, China
- HS Code:84293090
- Production Capacity:150 Sets , Year
Description
Basic Info.
Model NO. FCYJ-1.5E Gradeability 16 degree Weight 11600kg Max Shovel 73KN Max Traction 92KN Transport Package Container Shipment Specification 1.5m3 Trademark FUCHENG Origin Shandong, China HS Code 84293090 Production Capacity 150 Sets / YearProduct Description
New mining electric underground wheel loaders from Chinese manufacturerProduct Description:1. Advanced Ac three-phase asynchronous electric motor, supply customized electric Motor with various voltage; Compact structure, flexible and convenient operation.2.Equipped with American DANA Torque converter and Power shift Transmission.3.Excellent performance with Sauer, Parker pump, Parker valve. 4.Ergonomics designed compartment improve the control of bucket lifting and tilting, guarantee safety and minimal fatigue for operator. 5.Hydraulic double pipe working system, equipped with multi-disk wet braker, self-developed anti-skid differential mechanism of NO-SPIN. Advanced way of three-point suspension articulated, improving layout form of oscillating axle.6.Optional parts with ejector bucket and side dump buck.
Product parameters
Item | Parameters |
Motor Model | Y2-250-4 |
Motor Power | 55KW |
Motor Voltage | 380V |
Torque Converter | C273.1-295 |
Transmission System | RT20324-12 |
Drive Axle | NO-SPIN |
Braking System | Working Braking, Parking Brake |
Bucket Capacity | 1.5 m3 |
Max. Lifting Height | 3740mm |
Min. Ground Clearance | 250mm |
Total Weight | 11.6T |
Grade ability | 16° |
Max. Traction | 92KN |
Max. Shovel Force | 73KN |
Hydraulic Tank Capacity | 150L |
Running Speed | 0-10km/h |
Control Voltage | AC36V |
Lighting Voltage | AC24V |
Steering Angle | ±33° |
Min. Turning Radius | 5200mm |
Dimensions(L* W*H) | 7100 * 1420 * 2050mm |
Remarks:
The above parameters and configurations with mentioned parts' brand and models is subject to our standard production, we can supply optional parts and tailor-made proposals for customers.
1.Product Show:
![New mining electric underground wheel loaders from Chinese manufacturer](http://580557.com/uploads/image/2021/6e/e5/b7/65/f1e4a4bc7a0f81603e0a5f44b5848541.jpg)
![New mining electric underground wheel loaders from Chinese manufacturer](http://580557.com/uploads/image/2021/4b/98/45/d8/2142ed87da007170406571a36c4b30ec.jpg)
![New mining electric underground wheel loaders from Chinese manufacturer](http://580557.com/uploads/image/2021/49/b2/46/49/d456ed49ef3506d23286433f9ad89e17.jpg)
![New mining electric underground wheel loaders from Chinese manufacturer](http://580557.com/uploads/image/2021/79/e9/f6/cc/038710f860c054482523781e8c5fcd7a.jpg)
2.Product Details:
![New mining electric underground wheel loaders from Chinese manufacturer](http://580557.com/uploads/image/2021/30/00/58/32/b84fc18c64a8b03dd76181a0833af860.jpg)
![New mining electric underground wheel loaders from Chinese manufacturer](http://580557.com/uploads/image/2021/f7/27/8b/8e/c505bbda291267485fa161ed96105261.jpg)
![New mining electric underground wheel loaders from Chinese manufacturer](http://580557.com/uploads/image/2021/80/24/7e/78/ca738cd80329781925a4f2444fdcedfa.jpg)
3.packing and shipping:
![New mining electric underground wheel loaders from Chinese manufacturer](http://580557.com/uploads/image/2021/01/10/3c/ee/584ba2bf32d5bb75015e676921cffe42.jpg)
![New mining electric underground wheel loaders from Chinese manufacturer](http://580557.com/uploads/image/2021/f7/da/63/fe/67db630a1eed1393631a7a01251031d7.jpg)
4.Customer Factory Visit:
Fucheng mining equipment has passed ISO9001 quality management and CE certificate, widely exported to Southeast Asia, Europe, South America, Russia etc., and got consistent high praise by our customers.
On Oct 5th 2016 , purchase managers of Chile mining company came to our company and visited our factory before goods shipping. We introduced our products including electric and diesel scooptrams, mining underground trucks and drilling jumbos to our customers. He was very satisfied with the good performance and easy operation of our products and we arranged the shipment very smoothly that day.
Our products have been exported to Mexico, Australia, Africa, South America and other countries for almost 20years. The customers come to visit our factory each year to see our factory and product. After visiting, we established a long and successful partnership.
5.Company Information:
![New mining electric underground wheel loaders from Chinese manufacturer](http://580557.com/uploads/image/2021/31/76/43/32/e844f181e3f4c58330912484e0594f00.jpg)
Jinan Fucheng Hydraulic Equipment Co., Ltd was established in 2002.Fucheng has advanced R&D technology, sophisticate technical team and abundant experience.
We focus on the manufacture, trading, maintenance and service of underground mining equipment. At the same time, we supply import and export service for domestic & abroad customers.
Our underground mining equipment covers:(1).Underground Loader: 0.6 cbm - 6 cbm(2).Underground Truck: 8 tons - 35 tons(3).Drill Jumbo: 4 m2 - 50 m2(4).Scaling Jumbo: 4 m2 - 50 m2(5).Spare parts & maintenance
Fucheng key value is "Guarantee quality, Build a harmonious business, mutual development", we supply convenient & fast Pre-sale consultation and after-sale service, and take maintain of customers as our principle. Fucheng welcome all the friends both at home and abroad to visit and cooperate with us !
6.After sale Service :
1. The equipment warranty is one year.
2. We can guarantee annual maintenance, maintenance at any time, and ensure that solving the problems within 24 hours after arriving.
3. Our own professional designers will meet any of your requirements with the lowest price.
7. Warranty
(1) One year quality guarantee
(2) Other spare part could be supplied by OEM at cost prices.
(3) Regularly callback to know the vehicle's working status.
(4) The engineers are always on line to deal with unexpected needs.
8.Contact Information:
![New mining electric underground wheel loaders from Chinese manufacturer](http://580557.com/uploads/image/2021/7b/04/1a/33/11e7922bbb2ee42ab83edadb753abaab.jpg)
FAQ:
Q: Are you manufacturer or trading company ?
A: We are manufacturer. We can response to you quickly.
Q: What is the Payment terms ?
A: Usually by TT or LC, other terms could be negotiated.
Q: What is the delivery time ?
A: Normally the lead time is 30 days after receipt of down payment or LC.
Q: What is the warranty of the products ?
A: 12 months calculated from the goods arriving at the destination port.
Q: Do you provide equipment operation training?
A: Yes. We supply remote free online service. Or if need, we can send professional engineers to the working site for equipment installation, adjustment, and operation training.
Q: Can you customize the products?
A: Yes,we can customize as per your requirement.
Q: Where is the products are used?
A: The products are used for engineering, tunnels and all kinds of mines.
Welcome to contact us and obtain more information.
