Kaolin Grinding Ball Mill with Rubber Liner (1500X5700)

Zhengzhou Zhongding Heavy Duty Machine Manufacturing Co., Ltd.
  • Type：Ball Mill
  • Motor Type：DC Motor
  • Motor Power：15-1000kw
  • Application：Refractory Material, Silicate, Building Material
  • Materials：Feldspare,Zinc Ore, Copper Ore, Gold Ore,Silica
  • Condition：New

Base Info

  • Model NO.：1200x2800,2400x3600,3600x4500
  • Flowchart：Provided
  • Installation&Training：Provided
  • Grinding Method：Wet or Dry
  • Origin：China
  • Production Capacity：1-200t,H

Description

ModelSpeed (r/min)Max. weight of balls (t)Input size (mm)Output size (mm)Power (kw)Capacity (t/h)Weight (t)Φ900×1800371.8≤150.075-0.89150.5-23.4Φ900×2100372.3≤150.075-0.418.50.4-23.9Φ900×3000353.85≤250.075-0.4301.1-2.57.78Φ1200×2400354.6≤250.075-0.4301.3-3.28.65Φ1200×2800355.4≤250.075-0.4371.5-3.710.02Φ1200×4500358.6≤250.075-0.4452.7-6.7914Φ1500×3000299≤250.047-0.4753.3-8.214.12Φ1500×35002910.5≤250.047-0.4753.3-8.515.64Φ1500×45002913.5≤250.047-0.4904.5-1220Φ1500×57002917≤250.047-0.41102.6-1421.5Φ1830×30002413.5≤250.047-0.41354-1528Φ1830×36002414≤250.047-0.41354-1529Φ1830×45002420≤250.047-0.41554-1932Φ1830×70002431.5≤250.047-0.42106-2237.5Φ2100×30002218≤250.047-0.42106.4-2840.79Φ2100×36002220≤250.047-0.42107-2842Φ2100×40002221.5≤250.047-0.42107.6-2843.45Φ2200×360021.725≤250.047-0.42455.2-3244Φ2200×700021.746≤250.047-0.438015-3863Φ2400×36002128≤250.047-0.43208-6047Φ2400×45002135≤250.047-0.43808.5-6070.5Φ2700×360020.740≤250.047-0.440012-8075.5Φ2700×450020.748≤250.047-0.445012-90102Φ3200×40001865≤250.047-0.480030-180137

Note: Any change of technical data shall not be advised additionally.
Kaolin Grinding Ball Mill with Rubber Liner (1500X5700)
Application:Kaolin Grinding Ball Mill with Rubber Liner (1500X5700)
Features:Kaolin Grinding Ball Mill with Rubber Liner (1500X5700)
Rubber liner has low noise and long service time.
Kaolin Grinding Ball Mill with Rubber Liner (1500X5700)

Customer Case
Kaolin Grinding Ball Mill with Rubber Liner (1500X5700)

Mongolia Limestone Grinding Project

Input Size: 20mmOutput Size: 150meshCapacity: 50t/h

Equipment: Φ2100X2400 Ball Mill, Dust Collector, Ball Mill Spare Parts
