• Model NO.：GTX
• Certification：ISO, CE
• Rotation Speed：0.8-1.5 r,min
• Wheel Bucket Diameter：2200mm
• Screw Diameter：750mm
• Application：Ore
• Name：Rotary Sand Washing Equipment Gold Trommel Washing
• Keywords：Gold Washing Plant
• Color：Red
• Quality：High Level
• Install：Engineer Guide
• Motor：Chinese Brand
• Price：Negotible
• Material：Steel
• Operation：Easily
• Transport Package：Wooden Case
• Specification：GTX1030
• Trademark：hengchang
• Origin：China
• HS Code：8474100000
• Production Capacity：10 Set,Day

Basic Info.

Model NO. GTX Certification ISO, CE Rotation Speed 0.8-1.5 r/min Wheel Bucket Diameter 2200mm Screw Diameter 750mm Application Ore Name Rotary Sand Washing Equipment Gold Trommel Washing Keywords Gold Washing Plant Color Red Quality High Level Install Engineer Guide Motor Chinese Brand Price Negotible Material Steel Operation Easily Transport Package Wooden Case Specification GTX1030 Trademark hengchang Origin China HS Code 8474100000 Production Capacity 10 Set/Day

Product Description

Product Application

Rotary sand washing equipment gold trommel washing has single or double layers circular sieve to classify two to three kinds of different grades sand and stone which should be clearly deslimed. It is mainly used for washing ore before beneficiation operation system, and improving the ore grade for next processing step. it can be used for manganese ore, iron ore, limestone, tungsten, and silica ore, and so on.


Technical parameters of Rotary sand washing equipment gold trommel washing




Model	Drum Dimen sion(mm)	Screen Size(mm)	Rotate Speed(r/min)	Feeding Size(mm)	Water Consum ption(m3/h)	Capacity (t/h)	Power (kw)	Weight (t)
GTX1030	1000×3000	≤20	27.9	≤80	1	40	15	3.8
GTX1230	1200×3000	≤25	27.6	≤100	1.3	70	22	4.7
GTX1430	1400×3000	≤25	27.6	≤100	1.5	80	22	4.9
GTX1545	1500×4500	≤25	21	≤160	1.7	120	30	6.9



Main Features of Rotary sand washing equipment gold trommel washing

♦ Designed to break up alluvial gravels, clays and sand
♦ High capacity and high power scrubbing
♦The long drum of the scrubber retains material for longer, more vigorous washing for complete separation
♦ Thickening type steel plate for the drum
♦ Heavy duty bearing, gear and roller
♦ Wearable screen at the exit of drum for screening
♦ One high output electrical motor driving a gear system providing efficient torque
♦ The water with high pressure flushed the inwall of drum
♦ Can accept material up to 230mm
♦ Shell design less mass than conventional roller supported units - installation craneage requirement reduced



 Working process Of Rotary sand washing equipment gold trommel washing


The slurry material feeds into the drum where it is vigorously scrubbed, the soil matrix is broken up and the target mineral is released. The material is then screened through the rotating screen and waste is ejected. The screened material is then passed on to the concentrating modules for upgrading.

The rotary scrubber is an autogenous rotating drum scrubber, utilising pebbles and rocks within the feed source to fracture and disintegrate clays, agglomerates and soft oxides. Disintegrated material is homogeneously slurried within the drum, whilst the autogenous load is retained within the drum by reverse flights located at the drum discharge end.
Slurry and washed oversize overflows the drum discharge throat to the concentric exit trommels.

The scrubber spins slowly, similar to a giant washing machine. It churns the fines and oversize and water together, vigorously breaking up the soil matrix as well as liberating the target mineral from tough clay, schist's and rock.
After the fine (soil) is separated, the material is moved into the screen.

The rotating screen separates the oversize material from the fines (the fines are usually termed or categorized into less than 8mm).

Most of the freely (gravity) recoverable gold and or other recoverable mineral is contained in the - 8mm fines.
This material is then passed on to the downstream process equipment which can be in various forms such as centrifugal Concentrator, spirals, jigs etc.
