• Model NO.：DDC-8 Resistivity Meter
• Specification：iso
• Trademark：GOLD
• Origin：China
• HS Code：9030849000
• Production Capacity：100 Set,Mon

Basic Info.

Model NO. DDC-8 Resistivity Meter Specification iso Trademark GOLD Origin China HS Code 9030849000 Production Capacity 100 Set/Mon

Product Description

 Resistivity Meter, Geophysical Equipment, Geological Survey Instrument, Underground Explocation, Ground Water Detector, Water Finder




Main Applications and Features
By utilizing the apparent resistivity parameters, it is widely used in hydrology, environmental protection, engineering geophysical exploration, metal and non-metal mineral resources exploration.

Microcomputer controlled, direct-reading resistivity, various electrode arranging mode, data protection against power-failure

This geophysical equipment applies to Electrical Prospecting such as Vertical Electrical Sounding, Electrical Profiling, Charging Method and Spontaneous Potential Method, etc. On ground and in trench.



Technical Specifications
Geophysical Resistivity Meter Equipment Geological Survey Instrument Underground Exploration and Underground Ground Water Detector
Maximum Power Supply Voltage: 700V
Maximum Power Supply Current: 3A
Voltage Measuring Range: ± 3000mV?
Voltage Measurement Accuracy: ± 1.5%, ± 0.1 mV
Current Measuring Range: 0.1mA~3000mA
Current Measurement Accuracy: ± 1.5%, ± 0.1mA
SP Compensation Range: -1000mV ~ +1000mV
Instrument Input Impedance: >30MΩ
Working Temperature: -10° C~50° C
Volume: 244× 154× 237mm
Geophysical Resistivity Meter Equipment Geological Survey Instrument Underground Exploration and Underground Ground Water Detector


1. Ground Unit In English



2. Electrode for Measurement




Geophysical Resistivity Meter Equipment Geological Survey Instrument Underground Exploration and Underground Ground Water Detector
