• Model NO.：PYB2200
• Inlet Size：350mm
• Condition：New
• Warranty：One Year
• After-sales Service：Engineer Working in The Site
• Weight：80t
• Processing Power：590-1000t,H
• Shaft Speed：220r,Min
• Overall Dimensions：4622*3302*4470
• Transport Package：Exporting Standard
• Specification：many
• Trademark：STM Centbro
• Origin：Zhengzhou, China
• HS Code：8474209000
• Production Capacity：50 Sets Per Month

Product Introduction

^{STM Company is more focused on cone crusher production !
Its safety is high, maintenance is easy and performance is more stable.
Spring cone crusher is mainly used for medium and fine crushing of medium degree hardness materials and above, such as basalt, granite, river stone, iron ore, etc.
It is widely used in metallurgy, building material, mining and other fields.}

  Features:


1. Reliable structure, steady performance;

2. Long life for wear parts, low working cost;

3. Dry oil seal is adopted to isolate dust from lubricating oil and extend the service life of the equipment;
   ModelDiameter of crushing cone(mm)Feeding size(mm)Adjusting Range of Discharge Opening(mm)Capacity(t/h)Power(KW)Eccentric Shaft Rotate Speed(r/min)Weight(t)Overall Dimension(mm)PYB600Φ600≤ 7512-2515-253035652234 x 1370 x 1675PYD600Φ600≤ 353-135-23303565.32234 x 1370 x1675PYB900Φ900≤ 11515-5050-905533311.22692 x1640 x2350PYZ900Φ900≤ 605-2020-655533311.22692 x 1640 x 2350PYD900Φ900≤ 503-1315-505533311.32692 x 1640 x 2350PYB1200Φ1200≤ 14520-50110-16811030024.72790 x 1878 x 2844PYZ1200Φ1200≤ 1008-2542-135110300252970 x 1878 x 2844PYD1200Φ1200≤ 503-1518-10511030025.32790 x 1878 x 2844PYB1750Φ1750≤ 21525-50280-48016024550.33910 x 2894 x 3809PYZ1750Φ1750≤ 18510-30115-32016024550.33910 x 2894 x 3809PYD1750Φ1750≤ 855-1375-23016024550.23910 x 2894 x 3809PYB2200Φ2200≤ 30030-60490-750260-280220804622 x 3302 x 4470PYZ2200Φ2200≤ 23010-30200-580260-280220804622 x 3302 x4470
Clients Visit:
Certificates:Support:

We can not only provide the good machines, but also wholeheartedly provide the comprehensive for our clients. The series of professional technology service will make you have an excellent product experience.



After-sales service support :

After we signed the purchase contract and have a certain reputation guarantee, we will contact the professional group that responsible for ship bookings, commodity inspection, commercial invoices, packing list, insurance policy and so on, in order to provide you the perfect goods trading services, until the product you purchased properly to your hands.



We will send a professional and high levels installation engineer team at the same time the product properly to the destination, in order to supply you a full range of products installation services. For some typical problems, our rigorous installed engineers also will do some certain installation debugging training, etc.



Technological support :

STM Group has been largely adopting new technologies, new techniques and high-tech equipment. And STM Group also has strict and effective quality control system. We have obtained ISO9001:2000, TUV and CEquality system certificate.
