3500m3/Hr Sand &Slurry Cutter Suction Dredger for Mining/Desilting Project

Shandong Kehan Ecology Tech Co., Ltd.
  • Type:Cutter Suction Dredger
  • Power Type:Diesel
  • Cyclone Type:No
  • Slot Type:No
  • Customized:Customized
  • Condition:New

Base Info

  • Model NO.:JLCSD-500
  • Product Name:3500m3,Hr Sand &Slurry Cutter Suction Dredger
  • Dredging Capacity:3500m3,Hr
  • Dredging Depth:15m
  • Discharge Distance:1500m-2000m
  • Model:Jlcsd-500
  • Control System:Hydraulic Control System
  • Operation System:Siemens PLC Control System
  • Engine Power:1231kw
  • Engine Brand:Cummins Engine
  • Driven:Diesel Engine
  • Transport Package:in Containers
  • Specification:ISO9001: 2008
  • Trademark:JULONG
  • Origin:China
  • HS Code:89051000
  • Production Capacity:30 Sets,Year

Description

Basic Info.

Model NO. JLCSD-500 Product Name 3500m3/Hr Sand &Slurry Cutter Suction Dredger Dredging Capacity 3500m3/Hr Dredging Depth 15m Discharge Distance 1500m-2000m Model Jlcsd-500 Control System Hydraulic Control System Operation System Siemens PLC Control System Engine Power 1231kw Engine Brand Cummins Engine Driven Diesel Engine Transport Package in Containers Specification ISO9001: 2008 Trademark JULONG Origin China HS Code 89051000 Production Capacity 30 Sets/Year

Product Description

3500m3/hr Sand &Slurry Cutter Suction Dredger for Mining/Desilting Project

Product Description:
Julong new cutter suction sand dredger is perfectly suited for dredging sand, mud, gravel in the river or lake, Pond and lagoon. configuration of Cummins marine diesel engine and Shijiazhuang dredge pump, this model dredger can keep perfect and stable performance.
Besides, it can also be perfectly in dredging work of port construction and navigation channel maintenance with flexible operation. It can dredge sand, mud, clay, silt or other sediment in the water bed for passing vessel.

Technical Parameter:

ModelJLCSD200JLCSD250JLCSD300JLCSD400JLCSD450JLCSD500JLCSD550
Pump Capacity(m³/h)50080012002200300035004500
Max.Dredging Depth(m)8.010.012.014.015.016.018.0
Total Length(m)21.025.027.033.038.040.044.0
Hull Length(m)9.010.012.019.019.020.020.0
Total Height(m)1.41.61.61.82.02.02.2
Total Width(m)4.85.25.46.47.37.88.8
Engine Power(kw)22433655974689512311690
Suction/Discharge Pipe Dia(mm)250/200300/250350/300400/400500/450600/500650/550

Photo Gallery:
Julong Dredgers in Our Factory:
3500m3/Hr Sand &Slurry Cutter Suction Dredger for Mining/Desilting Project
Julong Dredgers in Assembling:
3500m3/Hr Sand &Slurry Cutter Suction Dredger for Mining/Desilting Project


Optional Parts:
3500m3/Hr Sand &Slurry Cutter Suction Dredger for Mining/Desilting Project

* Anchor Booms
* Spud Carriage
* Submersible Pump to increase the dredging depth
* Pump Booster
* GPS Positioning System

Working Range:
-- Sand Dredging

-- Mud Dredging

--Construction Dredging

--Mining Dredging

--Environmental Dredging

Product Features:
★ Modular design:
The pontoons and main spare parts are connected by the bolts and nuts, which means the dredger can be dismantled in the factory and mounted in the construction sites. Of course, the delivery time will be reduced a lot by containers.

★ World -class spare parts:
We use the best parts like Cummins disel engine and Simmens PLC controlling system, Shijiazhuang pump.......Also, we build a efficient system to optimize the flow the production so as to guarantee the quality and function of the dredgers.

★ Flexible in use:
The dredgers can be adapted to different circumstance like river and lake. The material like sand, stones, mud, salt can be easily sucked and discharged to the destination place.

Why you choose Julong?
1. Simple, rapid assembly and dismantling
2. Spare parts and floating pipe available
3. Transportable by road, rail or sea
4. Reliable hydraulic system
5. Fresh water engine cooling system
6. Low fuel consumption
7. Easy to operate
8. Good after-sales service

Our Service Gaurantee:
3500m3/Hr Sand &Slurry Cutter Suction Dredger for Mining/Desilting Project

* Julong company signs a long-time after-sales service agreement with customers.
* We provide rational and practical design according to customers' request.
* We send engineers to assemble and test the machine within the period as agreed in the  contract.
* Within warranty period, we provide free repair if quality problems emerge.
* We provide free training of operation and maintenance for customers.
* We supply high quality accessories in low price.
* We make an excellent filing of customers for long-term following-up service.

Our Customers:
3500m3/Hr Sand &Slurry Cutter Suction Dredger for Mining/Desilting Project

Julong dredgers have been exported to Asia, Africa, Europe, Oceania and South America. Julong dredgers are working in good state and benefiting clients both economical profit and ecological effect.

Shipping & Delivery:
3500m3/Hr Sand &Slurry Cutter Suction Dredger for Mining/Desilting Project

* Smaller size dredger will be transported by container, and engineers will go to job site to assembly, testing and training.

* Bigger size dredger with diapatchable constructure, will be transported by Trailer truck on land and by bulk cargo ship by sea.

Welcome to Julong!
