• Model NO.：Jaw Crusher
• Inlet Size：0-1500mm
• Condition：New
• Processed Materials：Stone
• Warranty：12 Months
• Transport Package：Transport Package
• Specification：<1300t,h
• Trademark：CHAENG
• Origin：Henan
• Production Capacity：<1300t,H

Basic Info.

Model NO. Jaw Crusher Inlet Size 0-1500mm Condition New Processed Materials Stone Warranty 12 Months Transport Package Transport Package Specification <1300t/h Trademark CHAENG Origin Henan Production Capacity <1300t/H

Product Description

Introduction of PE Series Jaw Crusher

PE series jaw crushers are mainly used for crushing all kinds of ores and bulk materials into medium size, and can crush the materials with compressive strength less than 320Mpa in both coarse and fine crushing ways. PE series has products with complete specifications and its feeding size is 0-1500mm, so it is the first choice for primary crushing. PE series jaw crusher is widely used in ore, metallurgy, building materials, highway, railway, water conservancy and chemical industries.

Jaw crusher working principle

The motor transmits power through belt, drives the moving jaw do periodic motion to the fixed jaw surround the eccentric shaft. The angle between toggle plate and moving jaw increases when moving jaw moves up. So the moving jaw closes to the fixed jaw, and the stuff will be crushed in multiple ways. The angle between toggle plate and moving jaw decreases when moving jaw moves down, the moving jaw of jaw crusher moves away from fixed jaw by the pulling force of rod and spring, the products after crushing will be discharged from the outlet of jaw crusher.
 Jaw crusher parameters


Model	Max. Feeding Size (mm)	Outlet Adjustment Range (mm)	Processing Capacity (t/h)	Eccentric shaft Speed (r/min)	Power (Kw)	Overall Dimension (mm)	Weight (t)
PE600×900	500	55-150	51-130	250	55-75	4613×3302×4638	12.6
PE750×1060	630	80-140	110-250	250	110	2660×2430×2800	28
PE900×1060	685	230-290	130-300	250	110	2970×2556×2800	31
PE900×1200	750	105-155	160-380	220	132	3380×2870×3330	39
PE1000×1200	850	205-300	310-550	200	132	3480×2876×3330	42
PE1200×1500	1020	150-300	400-800	180	200	4200×3300×3500	78.6
PE1500×1800	1200	220-350	600-1100	180	355	5100×3740×4937	124
PE1600×2100	1250	175-300	800-1300	160	450	5220×4990×4850	172
PEX300×1300	250	20-90	30-90	330	55-75	1750×2320×1724	11.5
PEX250×1200	210	25-60	20-60	330	55-75	2192×1900×1950	8.5
PEX250×1000	210	25-60	15-50	330	30-37	1550×1964×1380	7
PEX250×700	210	25-60	15-30	330	22-30	1667×1545×1020	5
PEX150×750	125	18-48	5-16	330	15	1200×1500×1200	3.8
PEX600×900	125	10-40	1-3	330	5.5	896×745×935	4.5

CHAENG's Strength

1.Based on high-end and advanced equipment
With large casting base, machining and assembling workshop, CHAENG has strong casting and processing strength. All the main engines for the turnkey project are self-made, and other supporting auxiliary machines are bought from excellent brands at home and abroad, which means that we can control the whole quality and construction period of the project.


2.Multiple patents, controlling the core technologies
The company has a professional technical team in many fields with more than 100 people, such as technology, equipment, hydraulic, electrical and civil engineering. So we can design the whole sandstone aggregate production line independently. We stick to independent research and innovation all the time, continuously optimize product performance and improve the technological content of products. We have research center of aggregate, powder and high-performance concrete, so we can provide scientific and professional sandstone aggregate production system solutions for the customers.
CHAENG has won man honorary awards, such as "top 100 suppliers in China cement industry", "top 10 innovative enterprise in China cement industry", "high-growth private enterprise in Henan Province", "technological innovation demonstration enterprise of  energy conservation and emission reduction in Henan Province", "National high-tech enterprise" and so on.

Our service
