Hims Wet Magnetic Separator for Iron Ore Dressing
Yueyang Dalishen Electromagnetic Machinery Co., Ltd.- Type：Magnetic Separator
- Voltage：220V
- Weight：>10T
- Material：Stainless Steel
- Material Feature：Heat Resistant
- Certification：ISO9001:2008, CE
Base Info
- Model NO.：DLS
- Energy Saving：Energy Saving
- Warranty：1 Year
- Color：Multi Color
- Customized：Customized
- Condition：New
- Mining Object：High Gradient Magnetic Separator
- Capacity (Solid)：0.05~250 T,H
- Max Ore-Feeding Size：1.3 mm
- Machine Weight：2~175 Tons
- Diameter of Ring：500~3000 mm
- Max Background Field：13000 GS
- Power(W)：10~85kw
- Capacity (Slurry)：0.5~650 M3,H
- Water Consumption：0.75~220 M,H
- Cooling Water Yield：1.5~6 M,H
- Transport Package：Seaworthy Package
- Specification：ISO9001: 2008
- Trademark：CiShen
- Origin：China
- HS Code：8474100000
- Production Capacity：10 Sets,Month
Description
Model
PartDLS-50 DLS-75 DLS-100 DLS-125 DLS-150 DLS-175 DLS-200 DLS-250 Ring Diameter
(mm) 500 750 1000 1250 1500 1750 2000 2500 RotationSpeed (r/min) 0-3 0-3 0-3 0-3 0-3 0-3 0-3 0-3 Max. Feeding Particles Size (mm) -1.0 -1.0 -1.3 -1.3 -1.3 -1.3 -1.3 -1.3 Suitable Size Distribution 30%~ 100% = -200 BBS mesh Slurry Density
(%) 10-40 10-40 10-40 10-40 10-40 10-40 10-40 10-40 Slurry Throughput
(m3/h) 0.5-1.0 1.0-2.0 12.5-20 20-50 50-100 75-150 100-200 180-450 Feeding CapacitySolid
(t/h) 0.05-0.25 0.1-0.5 4-7 10-18 20-30 30-50 50-80 80-150 Rated BG Intensity
(Tesla) 0-1.2 0-1.2 0-1.2 0-1.2 0-1.2 0-1.2 0-1.2 0-1.2 Rated Exciting Current
(A) 0-1200 0-850 0-650 0-850 0-950 0-1200 0-1200 0-1400 Rated Exciting Voltage
(V) 0-8.3 0-13 0-26.5 0-23 0-28 0-31 0-35 0-45 Rated Exciting Power
(kw) 0-10 0-11 0-17 0-19 0-27 0-37 0-43 0-63 Ring Motor Power
(kw) 0.37 0.55 1.1 2.2 4 5.5 7.5 11 Vibration Motor Power
(kw) 0.55 0.75 2.2 2.2 4 5.5 7.5 11 Vibration Stroke
(mm) 0-20 0-20 0-20 0-20 0-20 0-30 0-30 0-30 Vibration Frequency
(r/min) 0-300 0-300 0-300 0-300 0-300 0-300 0-300 0-300 Water Supply Pressure (MPa) 0.1-0.2 0.1-0.2 0.2-0.4 0.15-0.3 0.2-0.4 0.2-0.4 0.2-0.4 0.2-0.4 Water Consumption
(m3/h) 0.75-1.5 5~8 10-20 30-50 60-90 80-120 100-150 200-300 Cooling Water Quantity(m3/h) 1.5-2 1.5-2 2-2.5 2.5-3 3-4 4-5 5-6 6-7 MainBody Weight
(t) 1.5 3 6 14 20 32 48 102 Overall dimension
(mm) Length 1900 2000 2800 3400 3450 3900 4290 5200 Width 1580 1360 2200 2400 3050 3500 3800 4850 Height 1320 1680 2560 2640 3150 3800 4500 5560
