• Model NO.：HTSI08
• Origin：China
• HS Code：8474100000
• Production Capacity：30PCS,Month

Basic Info.

Model NO. HTSI08 Origin China HS Code 8474100000 Production Capacity 30PCS/Month

Product Description

Performance:
1. Using the principle of rolling conveying, the friction coefficient is small, the wear is light, and the screen holes are not blocked.
2. The roller support adopts an integral through-shaft structure, which runs smoothly, does not vibrate and has low noise.
3. The trommel screen adopt the split design, the structure is simple, and the replacement and maintenance are quick and convenient.
4. The trommel screen is safe and reliable in operation, with low power consumption, low energy consumption and obvious energy saving effect.
5. The trommel screen is a one-time investment, the investment capital is small, the processing capacity is large (the daily processing capacity is several thousand tons), and the recovery volume is particularly high.


Working principle:
When working, the motor is connected with the roller device through the reducer through the coupling, and the roller device is driven to rotate around its axis. When the material enters the drum device, due to the inclination and rotation of the drum device, the material on the screen surface is turned over and rolled, so that the qualified material is discharged through the outer screen of the drum, and the unqualified material is discharged through the end of the drum, which overcomes various problems. The screen sticking problem of the vibrating screen when screening wet materials improves the output and reliability of the screening system.
