Keda Hydraulic 18 Inch Sand Mining Dredge Mud Pump Dredging
Qingzhou Keda Environment Protection Machinery Co.,Ltd.- Type:Cutter Suction Dredger
- Power Type:Diesel
- Slot Type:CSD
- Customized:Customized
- Condition:New
- Warranty:1 Year
Base Info
- Model NO.:KDCSD-450
- Standard Dredging Depth:15m
- Pump Model:20,18
- Water Flow:3500m3,H
- Size:18inch
- Usage:Sand Dredging, Mud Dredging, Desilting
- Certificate:ISO9001:2008 Marine Certificate
- Engine:Cummins, Jichai, Weichai etc
- Pump:Customized
- Gearbox:Marine Grade
- Transport Package:Container
- Specification:18 inch
- Trademark:KEDA
- Origin:Weifang, Shandong
- HS Code:8905100000
- Production Capacity:30PCS,Year
Description
Basic Info.
Model NO. KDCSD-450 Standard Dredging Depth 15m Pump Model 20/18 Water Flow 3500m3/H Size 18inch Usage Sand Dredging, Mud Dredging, Desilting Certificate ISO9001:2008 Marine Certificate Engine Cummins, Jichai, Weichai etc Pump Customized Gearbox Marine Grade Transport Package Container Specification 18 inch Trademark KEDA Origin Weifang, Shandong HS Code 8905100000 Production Capacity 30PCS/YearProduct Description
Hydraulic 18 inch River Cutter Suction Dredger
I. PRODUCTS DESCRIPTION
1. Cutter Suction Dredger of steel construction, the non self-propelled, dismountable type, is able to berth and dredge at any waters both in the coastal area and inland rivers. The dredger can be used to excavate and transport cohesive sediment below the class III specified in code for dredging engineering construction technique issued by Ministry of Water Resources(MWR) of P. R. China.
2. It's hull consists of a main pontoon and two side pontoons. Is to be easy to dismantle or mount for transportation by road, rail or water, and is to be easy to reassemble at project site. The engines and dredge pump are located in the center pontoon, the 2 side pontoons serve as fuel bunkers, ballast tanks and store.
3. The dredger is powered by diesel engines. The main diesel engine is to drive the dredge pump and the auxiliary engine is to drive hydraulic system, including cutter, swing and ladder winches, anchor winches, and the spud rams etc.
4. The spacious control cabin is ergonomically designed with 360 degree view. All the operation buttons, swifts, indicators, gauges are equipped on the control desk. Only two operators can control all the dredger in the operation room.
5. The dredger is painted by 4 layers of marine paint to protect from the corrosion. The ZINC anode can be used to give better anti-corrosion function.
II. BASIC PARAMETERS
MODEL | Workload | Dredging Depth | Lift | Discharge distance |
csd150 | 450m3/h | 5m | 36m | 2500m |
csd200 | 750m3/h | 6m | 49m | 2000m |
csd250 | 1100m3/h | 10m | 56m | 2000m |
csd300 | 2200m3/h | 12m | 57m | 1500m |
csd350 | 3000m3/h | 12m | 58m | 1100m |
csd450 | 4000m3/h | 15m | 55m | 700m |
csd500 | 5000m3/h | 16m | 62m | 500m |
IV. PACKING AND SHIPPING
Way of Packing
* FLC&LCL Export standard container 20/40 GP.
* Steel support & iron sheet sea- worthy package.
* Load: Export software scientific loading work
Transportation
* By sea freight.
* MSK/MSC/APL/EMC/WANHAI/KLINE
* Air delivery services
* We will remind you before boat arrives.
V. OUR SERVICE
1. Rational and practical design according to customers' request proved.
2. Within warranty period, we provide free repair if quality problems emerge.
3. Engerneers are avaliable to service oversea to assemble and test the machine according to the contract.
4. Free training of the first batch of operater proved, any question or problem about the products can be answered via online support, phone calls or on-sit support 24 hours.
VI. FAQ
In order to provide you with efficient & suitable quotation and assistance for you, could you kindly tell me the following information:
1) Output capacity(m3/h)
2) Max. Dredging depth(m)
3) Discharge distance(m)
If you have any question about our products or company, please let us know, we will try our best to make you satisfied.
