• Model NO.：Nordberg VB83 Jaw
• Material：High Manganese Steel
• Color：Customized
• Drawing：Original or Customized
• Crusher Brands：Sandvik, Telsmith, Trio Nordberg Rexnord
• Delivery Time：15-30 Days
• Condition：New
• Type：Jaw Plate
• Use：Ore Mining
• Machine Type：Jaw Crusher
• Experience：More Than 10 Years
• Crusher Models：Vb46, Vb57, Vb67, Vb83, Vb93, Vb108vb0806, Vb0907, Vb10
• Transport Package：Steel Pallet
• Specification：MN13CR2, MN18CR2, Mn22cr2
• Trademark：CASTEEL
• Origin：China
• HS Code：8474900000
• Production Capacity：5000 Ton,Year

Basic Info.

Model NO. Nordberg VB83 Jaw Material High Manganese Steel Color Customized Drawing Original or Customized Crusher Brands Sandvik, Telsmith, Trio Nordberg Rexnord Delivery Time 15-30 Days Condition New Type Jaw Plate Use Ore Mining Machine Type Jaw Crusher Experience More Than 10 Years Crusher Models Vb46, Vb57, Vb67, Vb83, Vb93, Vb108vb0806, Vb0907, Vb10 Transport Package Steel Pallet Specification MN13CR2, MN18CR2, Mn22cr2 Trademark CASTEEL Origin China HS Code 8474900000 Production Capacity 5000 Ton/Year

Product Description

Product Names:
Jaw Plate,Jaw Tooth, Jaw Die, Jaw Teeth, Stationary jaw , Steady Plate, Fix plate, Fixed Jaw , Swing Jaw Plate, Movable Jaw,Jaw Fixed , Jaw Swing
Cheek Plate /Side Plate,side Liner,up Liner and lower Liner
Jaw Wedges /Taper Wedges, Jaw Lock
Toogle plate, toogle bearing, toogle seat.
Bowl Liner /Concave Ring, Cone Liner
Mantle Liner, Cone Liner
Blow Bar/ Hammer
Impactor Liner,Apron Liner, Impact Plate, Side Liner,Curtain Liner
Mill Liner ,SAG mill Liner,

Material Capacity & Following Standards

US	Australia	British	German	South Africa	Japan	China
ASTM A128/A532	AS2074 H1A/-H1B	BS3100/ BS4844	GX 130 MnCr2	SABS 407 Type 1 & 2	SCMnH11	GB/T 5680-2010

We Supported a wide range of alloys with different Heat treatment capabilities
Austentic Manganese steels 14%MN, MN13CR2, MN18CR2, MN22CR2 MN13CRMO, MN18CRMO, MN22CRMO
High chromium white cast irons Chrome 15%, Chrome 25%, Chrome 30% Cr25NiMo, Cr30NiMo and Etc
Alloy steels Various grades (SWB Germany)
High and low Carbon Steel
Ni-hard 2,3, 4
Customized Steel

Material	C	Mn	Si	Cr	Molly	Nikker	P	S	Suit to
Mn14Cr2	1.0-1.3	Mn:11-14	0.3-0.6	1.7-2.4	---	---	≤0.05	≤0.03	Jaw Plate, Side Plate,Mill Liner
Mn14Mo1	1.0-1.3	Mn:11-14	0.3-0.6	---	0.8-1.2	----	≤0.05	≤0.03	Shredder Hammer, Track Shoe
Mn18Cr2	1.1-1.4	Mn:17-20	0.3-0.6	1.7-2.4	---	----	≤0.05	≤0.03	Jaw Plate, Bowl Liner, Mantle
Mn18Cr2Mo0.6	1.1-1.4	Mn:17-20	0.3-0.6	1.7-2.4	0.6-0.8	---	≤0.05	≤0.03	Hard Abrassive Rock Crushing
Mn22Cr2Mo	1.1-1.4	Mn:20-24	0.3-0.6	1.7-2.4	----	----	≤0.05	≤0.03	Heavy Duty Concave,Mantle
KMTBCR15	2.8-3.2	Mn:0.6-0.8	0.6-0.8	14.5-15.5	0.2-0.3	0.2-0.3	≤0.06	≤0.06	Paddle Arm ,Tip And Mixer Liner
KMTBCR27	2.8-3.3	Mn:0.6-0.8	0.6-0.8	26.5-28	0.3-0.5	0.3-0.5	≤0.06	≤0.06	Blow Bar, Paddle tip ,VSI Parts,Anvil
KMTBCR30	2.8-3.3	Mn:0.6-0.8	0.6-0.8	28.5-30	0.3-0.5	0.3-0.5	≤0.06	≤0.06	Blow Bar, Paddle Tip, VSI Parts
Cr27Ni2Mo1	2.8-3.3	Mn:0.6-0.8	0.6-0.8	26.5-28	0.8-1.2	1.5-2.0	≤0.06	≤0.06	Heavy Duty Blow Bars
Ni-Hard	2.8-3.2	0.2-0.8	1.5-2.2	8.0-10.0	0.3-0.5	4.0-5.5	≤0.06	≤0.06	Mill Liner, Augers, Paddle Tip
Martensite Alloy Steel	0.3-0.6	0.8-1.5	≤1.2	1.8-2.3	0.2-1	0.5-0.8	≤0.06	≤0.06	Blow Bar, Mill Liner and etc
Carbon Steel	0.08-0.25	0.3-0.6	0.15-0.35	-----	----	----	≤0.045	≤0.045	Torch Ring,Shell , Bowl ,Cone

Applications:
Widely used in Mining Industry, Quarrying & Aggregate, metallurgical and Recycling industry, construction Plants, heavy engineering Industries , chemical industry and silicate industry for crushing hard and medium hard ore and rock, such as iron ore, limestone, copper ore, sandstone, quartz,Basalt,Granite, Building Waste ,Metal Scrap and so on.


Design and Development Capabilities:
With professional designers and efficient mould making, we can correctly and quickly implement new product development.
Our company trained a group of professional designers, who have gotten long term training in Our company; besides professional skills,we think highly of complementary relationships on the job,and built teamwork,enabled personal experience and collective wisdom to be brought into play or productively. As a result,we can cooperate with customers,swiftly understand and work with them,also gain the trust of painters.

Support Brands:

HISTORICAL BRANDS	AMERICA	EUROPE	Asian Model	CHINA	VSI	MOBILE CRUSHER
Allis Chalmers	Austin Western	I-Bag	Kawasaki	Shanbao	Barmac	Mccolsky
Svedala Araba	Lippmann	LORO PARISINI	Hitachi	Gator	Merlin	Rubber Master
Fuller Traylor	JCI /Astec	Terex Pegson	Kobelco	Liming	Sandvik	Kleemann Reiner
Krupp	Altairac	BL-Pegson	UBE	Shibang	Cemco	Tesab
Superior	McLanahan	Baxter	Nagoya	Dahongli	Remco	KPI-JCI
Flsmidth	Pioneer	CFBK El-Jay	Kemco	Vipeak	Canica	Lokomo Track
Boliden Allis	Eagle	Dragon	Nakayama	Leimeng	Trio	Powerscreen
Cedarapids	Hewitt Robins	BJD Crusher	Komatsu	Dongmeng	BHS	Finlay
Metso Mineral	Universal	Jaques	Inchon	Longyang	Nakayama	Striker
Norberg	Faco	SBM	Kamyong	SRH	Zhe Kuang	Extec
Symons	Osborn	Bergeaud	Samyong	Hongxing	NFLG	Hartl
Gyradisc	Kue-Ken	Atlas Copco	Minyu	Yifan	Shibang	Extec
Telsmith	PLC Hunwick	Parker	ChyiMeang	Dahua	Liming	Giporec
Brown Lenox	I-Rock	Goodwin Barsby	Shuangjin	Truston	Hongxing	Komatsu
Omnicone	Stedman	SheepBridge	Willam	MP Crusher	Bailike	Fintec
Hazemag	HMH,HRI	Sandvik	YNH	NMS	Dahongli	Keestrack

Manufacturing Process:

QC /Testing:
Provide measurement check, Metallographic, machinery performance, hardness, ultrasonic inspection, coloring flaw testing, ultrasonic flaw testing and result a report before shipping
