Gypsum Quartz Limestone Hammer Crusher Trituradora/Molino De Martillo Precio

Gongyi Hengchang Metallurgical Building Material Equipments Plant
  • Type:Mobile Crusher
  • Motor Type:AC Motor
  • Motor Power:110kw
  • Application:Mine
  • Materials:Limestone
  • Outlet Size:20-50mm

Base Info

  • Model NO.:PC
  • Inlet Size:150×750mm
  • Condition:New
  • Name:Hammer Crusher Trituradora,Molino De Martillo Prec
  • Keywords:Molino De Martillo Precio
  • Installation:Engineer Guide
  • After Sale Service:Maintenance
  • Material:High Manganese Steel
  • Max Feeding Size:100mm
  • Popular Models:PC400*300
  • Capacity:5-110 T,H
  • Weight:900-19000 Kg
  • Transport Package:Wooden Case, Standard Container
  • Specification:PC400*300
  • Trademark:Hengchang
  • Origin:China
  • HS Code:8474209000
  • Production Capacity:100 Set,Day

Description

Basic Info.

Model NO. PC Inlet Size 150×750mm Condition New Name Hammer Crusher Trituradora/Molino De Martillo Prec Keywords Molino De Martillo Precio Installation Engineer Guide After Sale Service Maintenance Material High Manganese Steel Max Feeding Size 100mm Popular Models PC400*300 Capacity 5-110 T/H Weight 900-19000 Kg Transport Package Wooden Case, Standard Container Specification PC400*300 Trademark Hengchang Origin China HS Code 8474209000 Production Capacity 100 Set/Day

Product Description

1.Product Description Of Pto Small Hammer Mill for Factory Direct Supply

It crushes things by the high speed collisions between the hammer and the materials and it is developed for both dry and wet crushing of brittle, medium-hard materials for the mining, cement, coal, metallurgic material, construction material, road building, and petroleum & chemical industries. it has the advantages of simple structure, large crushing ratio and high production efficiency. the grate gap of hammer crusher can be adjusted according to the user's different particle size requirements.

Gypsum Quartz Limestone Hammer Crusher Trituradora/Molino De Martillo Precio
2.Working principle Of Pto Small Hammer Mill for Factory Direct Supply

In the hammer mill crusher machine, the motor drives the rotor to rotate at a very high speed with the help of  the belt, and on the rotor there are series of hammers. which can deal with different kind of materials. When the materials get into the working area of hammers, it will be crushed immediately by the rotating hammers with high rotation speed .

Gypsum Quartz Limestone Hammer Crusher Trituradora/Molino De Martillo Precio
Gypsum Quartz Limestone Hammer Crusher Trituradora/Molino De Martillo Precio
3.Main Features and application
Gypsum Quartz Limestone Hammer Crusher Trituradora/Molino De Martillo Precio
1. High production capacity, high crushing ratio.
2. Low power consumption, uniform particle size.
3. Simple structure, easy to operate.
4. Low investment cost, easy management.
5. The enhancement rotor is designed with finite element analysis technology.
6. High crushing ratio. The crushing ratio ranges from 10 to 25 or even higher to 50.
7. The AMC alloy hammerhead enjoys a service life increased by 50~150%.
8. The theory of stone hitting effectively reduces the wear load of hammerhead and grid plate.
9. The military high strength artillery steel spindle is designed with vacuum duplex which increases the strength by 3-4 times.


4.delivery
Gypsum Quartz Limestone Hammer Crusher Trituradora/Molino De Martillo Precio
Gypsum Quartz Limestone Hammer Crusher Trituradora/Molino De Martillo Precio
5.Technical parameter of Pto Small Hammer Mill for Factory Direct Supply
Model Rotor

size(mm)
Rotor speed
(r/min)
Feeding size
(mm)ze
Output size
(mm)
Motor power
(kw)
Capacity
(t/h)
Weight

(kg)
PC400×300Φ400×3001440≤100≤107.55-10900
PC600×400Φ600×400960≤100≤1518.510-201500
PC800×600Φ800×600970≤120≤154518-242680
PC1000×800Φ1000×800990≤200≤1511030-505600
PC1000×1000Φ1000×1000990≤200≤1513230-608000
PC1200×1200Φ1200×1200750≤250≤2018090-11019000
6.Our Company
Gypsum Quartz Limestone Hammer Crusher Trituradora/Molino De Martillo Precio
Gypsum Quartz Limestone Hammer Crusher Trituradora/Molino De Martillo Precio
Gypsum Quartz Limestone Hammer Crusher Trituradora/Molino De Martillo Precio

Gypsum Quartz Limestone Hammer Crusher Trituradora/Molino De Martillo Precio
1.what's your raw material?rock,glass,limestone or others?
2.what's the input and output size of your raw material?
3.what's the capacity you need?tph?
