Mining Machinery

for Silica Sand, Feldspar Vertical Whims Magnetic Separator

Weifang Guote Mining Equipment Co., Ltd.
  • Type:Magnetic Separator
  • Voltage:220V
  • Weight:Depend on Different Models
  • Material:Carbon Steel
  • Material Feature:Heat Resistant
  • Certification:ISO9001:2008, CE

Base Info

  • Model NO.:GTLH
  • Energy Saving:Energy Saving
  • Warranty:1 Year
  • Color:Multi Color
  • Customized:Customized
  • Condition:New
  • Rated Background Magnetic Field:1.4t (1.8t)
  • Dielectric Induced Magnetic Field:2.1t (3.6t)
  • Usage:Mining Separatoion
  • Installation:Engineer Guide
  • Feeding Size:<1.2mm
  • Function:Deironing Purification
  • Slurry Density(%):10-40
  • Ring Speed(R/Min):3
  • Pulsion Stroke:0-30
  • Excitation Voltage:0-514(700)
  • Transport Package:Standard Sea Worthy Packing for Drum Type Wet Magn
  • Specification:depend on different models
  • Trademark:Guote
  • Origin:Weifang
  • HS Code:8474100000
  • Production Capacity:50sets,Month

Description

1(0.6)Constant current continuously adjustableMagnetic field1.9(1.2)Constant current continuously adjustableEnergizing power(KW)

≤10(6)

≤13(8)

≤17(10)≤19(12)≤27(15.5)≤37(23)≤42(29)≤57(37)≤74(48)Handing capacity(t/h)0.1-0.30.1-0.53.5-7.510-2020-3030-5050-8080-150150-250Slurry throughput(m3/h)0.25-0.55-1012.5-2020-5050-10075-150100-200200-400360-650Magnetizing current(A)63728592105124130153185Slurry density(%)10-40Feed particle size-1.0-1.0-1.2-1.2-1.2-1.2-1.2-1.2-1.2

Ring speed

(r/min)

3Ring diameter(mm)Φ500Φ750Φ1000Φ1250Φ1500Φ1750Φ2000Φ2500Φ3000Ring motor power(KW)0.370.751.11.5345.51118.5Ripply motor power(KW)0.371.52.23347.51118.5Pulsion stroke(mm)0-30(Mechanically adjustable)Pulsion frequency0-300(Variable frequency conversion)Excitation voltage(DCV)0-409(280)(Change with current)Unloading water pressure(Mpa)0.1-0.20.1-0.20.2-0.40.2-0.40.2-0.40.2-0.50.2-0.40.2-0.40.2-0.4Water supply pressure(m3/h)0.65-1.41.4-2.58-1212-2020-3030-5050-100100-150150-250Host weight(t)3(1.5)5(3.5)9(7)14(11)24(20)35(28)50(39)105(83)150(135)Maximum part weight(t)0.3(0.25)0.6(0.5)2.2(2)4(3.5)5(5)11(9)16(13)23(18)24(19)Dimensions(mm)

1800*

1400*

1320

2000*

1360*

1680

2700*

2000*

2400

3200*

2340*

2700

3600*

2900*

3200

3900*

3300*

3800

4200*

3650*

4200

5800*

6000*

5400

7600*

6500*

7200


for Silica Sand, Feldspar Vertical Whims Magnetic Separator

for Silica Sand, Feldspar Vertical Whims Magnetic Separator

Working principle:

Pulp through the feeding tube into the feed hopper, pulp along the magnetic gap through the swivel,

high permeability of the stainless steel rods inside the ring of the magnetic induction medium
magnetized in the background magnetic field, form a high gradient magnetic field, magnetic medium
pulp in the magnetic particles are adsorbed on the surface of magnetic medium,

the swivel rotation was taken to to the top of the magnetic field area, by flushing with rinse water
pressure, the magnetic materials into concentrate in the bucket, non-magnetic particles along the
magnetic gap into the tailings under drained bucket in order to realize the separation of material

Swivel lower magnetic medium of submerged within the ore slurry surface,at the same time of slurry injection, installed at the side of the tailings boxes of reciprocating motion
stroke box constantly doing, make through tympanic membrane separation indoor pulp do fluctuate,the pulsating flow physical ore grain group always maintain loose state in the process of sorting,
effectively remove the particles in material, significantly improve the grade of concentrate

for Silica Sand, Feldspar Vertical Whims Magnetic Separatorfor Silica Sand, Feldspar Vertical Whims Magnetic Separator

Certification

for Silica Sand, Feldspar Vertical Whims Magnetic Separatorfor Silica Sand, Feldspar Vertical Whims Magnetic Separatorfor Silica Sand, Feldspar Vertical Whims Magnetic Separator
FAQ

Q: Why we believe in Weifang GuoteMining Equipment  Company?
A: 1. More than 10 years experience.


Q. We are the leading professional supplier of mining equipments and service for quartz mining equipment industry.
A. All products achieved ISO9001:2000 quality management certificate and EU CE certificate.



Q: Delivery time
A: The lead time is 10-30 days, delivery time will vary depending on the type of the machine, shipping method selected and part availability.



Q: Payment terms
A: Accepted Payment Type: T/T, L/C, Western Union, Cash.
After sign the contract, pay the 30% deposit of total purchase price and pay the full payment before delivery.



Q: What will you do if the machine is broken down?
A: The Products warranty is one year. We will provide the technical advice and find the solution immediately for you when the machine is in trouble. For those wear parts, we guarantee the high quality parts for long-term supply.



Q: What should I do if I want to get a best quotation?
A: If you want a suitable type for you, please let us know your material and capacity.
