• Model NO.：1.2*4 Sand Gold Separator Machine
• Energy Saving：Energy Saving
• Warranty：1 Year
• Color：Blue or as Your Request
• Customized：as Your Request
• Condition：New
• Dimension (mm)：3200X1200X730mm
• Capacity (M³/H)：20-25
• Feeding Size (mm)：<20
• Slurry Density (%)：30
• Concentration Cleaning up Cycle (H)：4
• Transport Package：by FCL or LCL
• Specification：Standard
• Trademark：Hengchang Sand Gold Separator Machine
• Origin：Jiangxi Province, China
• HS Code：8474100000
• Production Capacity：100sets,Month

Basic Info.

Model NO. 1.2*4 Sand Gold Separator Machine Energy Saving Energy Saving Warranty 1 Year Color Blue or as Your Request Customized as Your Request Condition New Dimension (mm) 3200X1200X730mm Capacity (M³/H) 20-25 Feeding Size (mm) <20 Slurry Density (%) 30 Concentration Cleaning up Cycle (H) 4 Transport Package by FCL or LCL Specification Standard Trademark Hengchang Sand Gold Separator Machine Origin Jiangxi Province, China HS Code 8474100000 Production Capacity 100sets/Month

Product Description

Namibia River Sand Gold Separator Machine

Working principle of Sand Gold Separator Machine:
There is a rubber pad on the shaking chute bed, which is driven by electric motor and can move up and down .While moving the light gravity material will be flew out by the water, heavy gravity material such as gold & other metal will fall down and be kept.

Our power sluice machine is designed with the "HYDRAULIC" controller instead of the old type. it is more convenient to clean up the concentrate on  the chute.and save time as well. also the slope can easily controlled by "HYDRAULIC".It's our patented product, we are the first factory developed this design power sluice machine. its size is 6000 by 1100 by 1000 mm,and have been sale well all around the world.


Product Application of Sand Gold Separator Machine

The Sluice Box works with the gold trommel screen to recover gold roughly.

1. Reasonable structural design, convenient for transporting;
2. High degree of automation, Multi-machine joint working high gold handling capacity with the daily capacity
up to 2000m3
3.Suitable for various areas, washing and separation are excellent in muddy areas of mines; It can also be
suitable for processing minerals that may contain gravels and boulders;
4. Applicable to recycling bar gold, nuggets, slices and gold particles;
5. High degree of washing and recovery rate.
SPECIFICATIONS FOR Sand Gold Separator Machine

Model	FGS-12	FGS-15
Dimension (mm)	3200x1200x730	4000x1500x730
Capacity (m³/h)	20-25	30-35
Feeding size (mm)	<20	<20
Slurry density (%)	30	30
Water required (m³/h)	40-50	60-80
Motor power (KW)	Driving motor 1.1kw Lifting motor 0.8KW	Driving motor 2.2kw Lifting motor 0.8KW
Recovery (%)	90	90
Frequency (shift/min)	28-30	28-30
Slope angle for installation	6°-7°	6°-7°
Concentration Cleaning Up Cycle (h)	4	4
Weight (kg)	750	1100

PICTURES OF Sand Gold Separator Machine








About us
Jiangxi Hengchang Mining Machinery Manufacturing Co., Ltd. is located in No.3 Chuangye Road. Guzhang In dustrial Park. Shicheng County. Ganzhou City. Jiangxi Province. China.Our company is engaged in the mineral processing equipment research, development, design and production for many years history, has accumulated rich experience in design and production. Enterprise in mineral processing equipment industry has had a positive effect, set up the good reputation. And mainly the manufacture of the products like as Shaking table. Flotation equipment. Crushing equipment. Magnetic separator. Screening equipment. Classifying equipment. Agitation tank, Feeding equipment. Gravity separation equipment. Wet separation equipment. Spiral chute. Saw-tooth wave jig and Diaphragm Jig. Grinding equipment. Ball mill. Slurry pump. Centrifugal pump, Conveying equipment.

We manufacture various types of mineral processing machinery and equipment according to our customers' requirements. Our products are widely used for sorting gold, silver, copper, iron, tungsten,lead. zinc. tin. molybdenum, nickel, tantalum, niobium, manganese ore, coal, monazite, rutile,diamonds, other precious metals and precious metals mine, and for the flotation colored, black metal,precious metals and other minerals. And we have export qualifications, our products sell well all over the world for several years, especially exported to Brazil. India. Indonesia.South Africa. Somalia, Philippines. Malaysia. Sudan, Nigeria. Russia, Ghana. Kazakhstan Kyrgyzstan.Cambodia,Vietnam,Korea,Mongolia and other countries.




8. Our service:

 1.Pre-sale services:
 (1)Select equipment model;
 (2) Design and manufactLire products according to clients' special requirement;
 (3)Train technical personnel for dients.
2.Services during the sale:
(1) Pre-check and accept products ahead of delivery;
(2)help clients to draft solving plans.

3. After-sale services:
(1) Assist dients to prepare for the first construction scheme;
(2)Install and debug the equipment;
(3) Train the first-line operators on site;


9. FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.not dealer.Direct factory sale makes price more competitive.


Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.


Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
