Mining Machinery

Qingzhou Keda Gold Mining Concentrator

Qingzhou Keda Environment Protection Machinery Co.,Ltd.
  • Type:Gravity Separator
  • Voltage:220V
  • Weight:1300kg-1500kg
  • Material:Stainless Steel
  • Material Feature:Oil, Heat, Fire Resistant
  • Certification:ISO9001:2008, CE

Base Info

  • Model NO.:KDLXJ60
  • Energy Saving:Energy Saving
  • Warranty:Six Months or One Year
  • Color:Customized
  • Customized:Customized
  • Condition:New
  • After-Sales Service Provided:Supply
  • Transport Package:Wooden or Other, as Customer′s Request
  • Specification:CE, Patent, ISO9001: 2008
  • Trademark:KEDA
  • Origin:Shandong, China
  • HS Code:847510000
  • Production Capacity:20sets,Month

Description

ModelSTL19STL30STL60STL80STL100Capapcity T/H0.25-0.303-515-2040-5080-100Feed particles mm0-30-40-60-60-6Feed density %0-50%0-50%0-50%0-50%0-50%Recoil of water T/H1.5-24-610-1517-2540-60Concentrate production
 (kg per time)2-310-2030-4060-7070-80Motor Power kw0.7537.51118.5Cone rotational speed800600460400360Water Pressure MPa0.040.10.160.180.2Overall Size mm790×785×7901150×1360×12501970×1670×17502300×1800×22002500×2000×2400Weight300kg500kg1300kg1800kg2800
2.The Description for Centrifuge
       Gold centrifugal concentrator  is an efficient equipment for recovering free gold in all particle size ranges,specially for recovery of fine gold which is lost during the operation of the gravitational concentrators(sluice boxes and jigs).  It can be used not only for placer gold mining, but also for hard rock mining to recover the natural gold, replacing amalgamation, and recover gold from the old tailings.The fact shows that the recovery  rate can be as high as 95%, and the concentrating ratio is up to 1,000 times.

3. Feature
--- High efficiency, recovery rate can reach more than 90%, Placer gold recovery rate can reach more than 95%.
--- Easy and convinient for operation and maintenance.
---Work capacity:15-20t/h
--- Diesel engine motor available
Qingzhou Keda Gold Mining ConcentratorQingzhou Keda Gold Mining Concentrator
