Australia 500tph Alluvial Gold Ore Washing Plant Rotary Trommel Scrubber

Jiangxi Gandong Mining Equipment Machinery Manufacturer
  • Type:Rotary Clay Washing
  • Voltage:380V
  • Weight:68t
  • Material:Carbon Steel
  • Material Feature:Oil Resistant
  • Certification:ISO9001:2008, ISO9001:2000, CE

Base Info

  • Model NO.:RXT3210 RXT1030 RXT1230 RXT1545 RXT2060 RXT2265
  • Energy Saving:Energy Saving
  • Warranty:3 Years
  • Color:as Custom′s Request
  • Customized:Customized
  • Condition:New
  • After-sales Service:Engineer Available Service Oversea
  • Application:Washing Mineral, Gold, Sand
  • Machine Type:Washing Machine
  • Model Size:Optional
  • Quality:ISO9001:2008
  • Install:Supply.
  • Training:Supply.
  • Testing:Supply.
  • Feeding Size (mm):230.
  • Transport Package:Nude in Container
  • Specification:SGS, ISO9001: 2008
  • Trademark:GANDONG
  • Origin:China
  • HS Code:84741000
  • Production Capacity:1000 Sets,Year

Description

Basic Info.

Model NO. RXT3210 RXT1030 RXT1230 RXT1545 RXT2060 RXT2265 Energy Saving Energy Saving Warranty 3 Years Color as Custom′s Request Customized Customized Condition New After-sales Service Engineer Available Service Oversea Application Washing Mineral, Gold, Sand Machine Type Washing Machine Model Size Optional Quality ISO9001:2008 Install Supply. Training Supply. Testing Supply. Feeding Size (mm) 230. Transport Package Nude in Container Specification SGS, ISO9001: 2008 Trademark GANDONG Origin China HS Code 84741000 Production Capacity 1000 Sets/Year

Product Description

Rotary Scrubber


Specifications

1.Designed to break up alluvial gravels,clays,sand
2.High capacity and high power scrubbing
3.Can accept material up to 230mm

The slurry material feeds into the drum where it is vigorously scrubbed, the soil matrix is broken up and the target mineral is released. The material is then screened through the rotating screen and waste is ejected. The screened material is then passed on to the concentrating modules for upgrading.



Features

Designed to break up alluvial gravels, clays and sanD
High capacity and high power scrubbing
The long drum of the scrubber retains material for longer, more vigorous washing for complete separation
One high output electrical motor driving a gear system providing efficient torque
Adjustable rotary speed
The water with high pressure flushed the inwall of drum
Can accept material up to 230mm
Mechanical sealing of inlet chute minimal spillage when over feeding
Drive loads absorbed within the drive frame and pivoting drive frame design Foundations only have to support vertical load and are not critical for alignment ie minimal cost
Shell design less mass than conventional roller supported units installation craneage requirement reduced



Descriptions



The rotary scrubber is an autogenous rotating drum scrubber, utilising pebbles and rocks within the feed source to fracture and disintegrate clays, agglomerates and soft oxides. Disintegrated material is homogeneously slurried within the drum, whilst the autogenous load is retained within the drum by reverse flights located at the drum discharge end. Slurry and washed oversize overflows the drum discharge throat to the concentric exit trommels.

The scrubber spins slowly, similar to a giant washing machine. It churns the fines and oversize and water together, vigorously breaking up the soil matrix as well as liberating the target mineral from tough clay, schist's and rock.

After the fine (soil) is separated, the material is moved into the screen. The rotating screen separates the oversize material from the fines (the fines are usually termed or categorized into less than 8mm). Most of the freely (gravity) recoverable gold and or other recoverable mineral is contained in the 8mm fines.

This material is then passed on to the downstream process equipment which can be in various forms such as centrifugal Concentrator, spirals, jigs etc.

Below pictures are for our Australia client, who bought two sets from us, one in 2020, after seeing our rotary scrubber's high performance, they bought a same one in 2021.

Drum diameter: 3200mm      Drum length: 10m
Australia 500tph Alluvial Gold Ore Washing Plant Rotary Trommel ScrubberAustralia 500tph Alluvial Gold Ore Washing Plant Rotary Trommel ScrubberAustralia 500tph Alluvial Gold Ore Washing Plant Rotary Trommel ScrubberAustralia 500tph Alluvial Gold Ore Washing Plant Rotary Trommel ScrubberAustralia 500tph Alluvial Gold Ore Washing Plant Rotary Trommel ScrubberAustralia 500tph Alluvial Gold Ore Washing Plant Rotary Trommel ScrubberAustralia 500tph Alluvial Gold Ore Washing Plant Rotary Trommel Scrubber



Model

Drum Size (m)

Screen size (mm)

Feeding size (mm)

Water pressure (Mpa)

Every ton of ore water required
(M3/t)

Capacity (T/h)

Rotation speed (r/min)

PowerKw)

Weight (Kg)
RXT1030Φ1.0×3.0≥5≤1000.4~0.51.5~430~5025~28154800
RXT1230Φ1.2×3.0≥5≤1000.4~0.51.5~450~7023~2518.55800
RXT1545Φ1.5×4.5≥5≤1500.4~0.51.5~470~12018~22306900
RXT1560Φ1.5×6.0≥5≤1500.4~0.51.5~480~13018~22378300
RXT1845Φ1.8×4.5≥5≤1700.4~0.51.5~490~13020~214511800
RXT1860Φ1.8×6.0≥5≤1700.4~0.51.5~4100~14020~214512800
RXT2060Φ2.0×6.0≥5≤2100.4~0.51.5~4120~16019~205514800
RXT2265Φ2.2×6.5≥5≤2300.4~0.51.5~4160~18019~205516500
 We can all models as you need, our professional engineer team has more than 20 years experience, all equipments can be customized.
