Mining Machinery

Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral ...

Jiangxi Province County Mining Machinery Factory
  • Voltage:380V
  • Weight:10T

Base Info

  • Model NO.:JXSC-1500
  • Material:Casting Steel
  • Material Feature:Heat Resistant
  • Certification:ISO9001:2008, ISO9001:2000, CE
  • Energy Saving:Energy Saving
  • Warranty:1 Year
  • Color:Blue
  • Customized:Customized
  • Condition:New
  • After-sales Service:Provided
  • Diameter of Sieve Tube:1500mm
  • Motor Power:30kw
  • Capacity Per Hour:70-100kg
  • Feeding Size:Less Than 230mm
  • Rotation Speed:16 R,Min
  • Screen Size:Less Than 50mm
  • Angle of Inclination:Less Than 10 Degree
  • Transport Package:Standard Packaging, Shipping by Container
  • Trademark:JXSC or customized
  • Origin:Ganzhou, Jiangxi
  • Production Capacity:200sets,Month
  • Package size per unit product:300.00cm * 200.00cm * 200.00cm
  • Gross weight per unit product:2000.000kg

Description

Basic Info.

Model NO. JXSC-1500 Material Casting Steel Material Feature Heat Resistant Certification ISO9001:2008, ISO9001:2000, CE Energy Saving Energy Saving Warranty 1 Year Color Blue Customized Customized Condition New After-sales Service Provided Diameter of Sieve Tube 1500mm Motor Power 30kw Capacity Per Hour 70-100kg Feeding Size Less Than 230mm Rotation Speed 16 R/Min Screen Size Less Than 50mm Angle of Inclination Less Than 10 Degree Transport Package Standard Packaging, Shipping by Container Trademark JXSC or customized Origin Ganzhou, Jiangxi Production Capacity 200sets/Month

Packaging & Delivery

Package size per unit product 300.00cm * 200.00cm * 200.00cm Gross weight per unit product 2000.000kg

Product Description

Trommel Scrubber Washing Machine Application

Trommel Scrubber Washing Machine is suitable to wash clay ore and sieve all kinds of material that with sticky clay, such as alluvial gold / tin ore/ tungsten ore/ chrome ore/ coltan ore/ beach sand/ zircon sand/ diamond/iron sand/manganese ore/silica sand/ kaolin clay/ gravel stone,ect.
We have sold many trommel scrubber for customers' mining projects, most projects are provided complete line equipment by JXSC factory, not only trommel scrubber. below share some actual proejct cases we supplied for different ores mining projets.


Project case 1: 100TPH Nigeria Coltan Mining Project (tantalum-niobium ore)
Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale

JXSC factory designed efficient process flowsheet and provided plant layout drawing and sent engineer to mine site for providing installation sevice.
We not only provided the trommel scrubber washing machine, but also provided the full line equipment for this project,including vibrating feeder>trommel scrubber>jig separator>shaking table>vibrating screen>hammer crusher>slurry pump>water pump>three disc dry magnetic separator.


Project case 2: 50TPH Alluvial Gold Ore Mining Project in Nigeria

Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale

Project case 3: 200TPH Ilmenite Ore Mining Project in Australia
Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale
Project case 4: 200TPH Diamond Mining Project in Angola
Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale
Trommel Scrubber Washing Machine Introduction

Trommel Scrubber is a main washing equipment in mining industrial, widely used for washing alluvial type/sand type ores and stones, which with much sticky clay, with much good washing effect for clay.
Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale
Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale

This machine with two parts: rotary scrubber and screen. The rotary scrubber is for washing ore, screen is for sieving different size particles after washing.

Screen Material

1. Manganese steel: normal material, not easy to replace, 2-3 monthes life time.
2. PU material: wear-resistance, long life time 4-6 monthes, corrosion resistant, splicing technology, replacable, very easy to replace.
3. Stainless steel material : wear-resistance, long life time 4-6 monthes, corrosion resistant, splicing technology, not easy to replace.

Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale


Linning Plate Inside Barrel

In order to increase the washing effect, we always put linning plates insider barrel scrubber part, it can be made below two kinds material:
1. Iron material spiral plates: normal material, can't be replaceable, welded inside drum.
2. Natual Rubber lined plates: wear-resistance, long life time, corrosion resistant, fixed with screw, replacable, easy to replace.

Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale

Rotary Scrubber Washer Main structure

1. Drum scrubber : For washing the clay.
2. Trommel scrubber Inner plate: separating the clay and ores, washing more clean the clay.
3. Trommel scrubber Sieving screen: for sieving different sizes ores, the screen mesh size& layer quantity & screen materials can be made according to customer need.
4. Diamond washing trommel scrubber Motor: electric or diesel according to your needs.
5. Carrier rollers: For support the drum
6. Gear, Reduction Box, coupling.
7. Machine Frame: Supporting the reduction box and motor.



Trommel Scrubber Washing Machine Technical Parameters


ModelScreen Size (MM)Rotation Speed    (R/Min)Feeding size     (mm)Angle of inclination      (degree)     Capacity         (T/H)   Power      (KW)
JXSC-400≤2027.9≤80≤101-53
JXSC-600≤2527.6≤80≤105-105
JXSC-750≤2527.6≤100≤1010-307.5
JXSC-900≤2527.6≤100≤1030-5011
JXSC-1200≤2517≤160≤1050-7015
JXSC-1500≤5016≤230≤1070-10030
JXSC-1800≤5016≤230≤10110-15037
JXSC-2100≤5016≤230≤10150-18045


Packing & Shipping

Minerals Washing Trommel Scrubber Packing/Loading

1.Gold Washing Scrubber spare parts would be packed in wooden boxes to avoid broken.

2. Gold Washing Scrubber are fixed and loaded in container directly.

Minerals Washing Trommel Scrubber Shipping

1. Gold Washing Scrubber are shipped in Flat Containers by sea.

2. Gold Washing Scrubber can be also shipped by air if customers request.

Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale


Our company
Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale

JXSC Mining Machinery Factory

JXSC Factory is an experienced supplier of complete set mining equipments, professional at providing complete set processing equipments for Gold ore /Tin ore /Tungsten ore /Iron ore / Diamond/ Coltan ore / Silica sand / Zircon sand/ Black sand/Chrome ore, ect. As well as complete set small lab mining machines.

Our Core Advantages as below:
1.+30 years history FACTORY at mining machinery
2.Provide engineer team after sales service
3.Provide Complete set mineral processing plant
4.Provide Sample testing service in factory lab for free
5.Provide professional Mining Solution Consulting

Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale

Our service


Pre-Sales Service

*Inquiry and consulting support
*Ore sample testing support
*View our Factory
*Design Flowchart

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* 1 year warranty




* Engineers available to service machinery overseas,below site pictures are from customer's mine site,our engineers are guiding installation&commission&training at site.Alluvial Gold Trommel Scrubber Washing Plant Mobile Rotary Mining Ore Recover Mineral Waschanlage Sieve Washing Machine for China Sale
