• Model NO.：DGCSD300
• Capacity：3500 Cbm,H
• Dredging Depth：15 M
• Discharge Distance：1500 M
• Engine Brand：Cummins
• Installed Power：1231 Kw
• Discharge Pipe Dia.：500 mm
• Cutter Power：170 Kw
• Control System：Hydraulic PLC System
• Weight：140 Tons
• Size：12inch
• Transport Package：Bulk Vessel
• Specification：Customized
• Trademark：Dragon
• Origin：China
• HS Code：8905100000
• Production Capacity：35PCS Per Year

Basic Info.

Model NO. DGCSD300 Capacity 3500 Cbm/H Dredging Depth 15 M Discharge Distance 1500 M Engine Brand Cummins Installed Power 1231 Kw Discharge Pipe Dia. 500 mm Cutter Power 170 Kw Control System Hydraulic PLC System Weight 140 Tons Size 12inch Transport Package Bulk Vessel Specification Customized Trademark Dragon Origin China HS Code 8905100000 Production Capacity 35PCS Per Year

Product Description

Submersible Pump Large Capacity Long Discharging Distance High Quality Moderate Price  12 inch Customized Cutter Suction Dredger Mud Dredger Sand Dredger

Introduction
DRAGON dredgers are known for their high efficiency, robust construction, unbeatable economies of scale and lower operating costs, with the reliability and ease of use for operating in all conditions. The latest series is designed to be even more sustainable, safer and efficient.
Their modular construction means they are easy to transport and can be commissioned quickly at dredging site. They can be delivered with a complete and integrated package of equipment and service, including work boats, spare parts, training, dredging consultancy and maintenance support.

Strong and high efficiency Pump


All the dredger system will be tested in the subsupplier's factory and in our factory before delivery.


The modular design makes the transportation easier and faster. It can be transported by truck or railways.




Specification

Model	DGCSD200	DGCSD250	DGCSD300	DGCSD400	DGCSD500	DGCSD600
Overall Dimension	22 x 5.0 x 1.5m	25 x 5.2 x 1.6m	27 x 5.4 x 1.6m	32 x 6.4 x 1.8m	39 x 7.8 x 2.2m	44 x 8.8 x 2.4m
Max. Capacity	600 m3/hr	900 m3/hr	1300 m3/hr	2100 m3/hr	3500 m3/hr	5000 m3/hr
Max. Dredging Depth	8 m	10 m	12 m	15 m	16 m	18 m
Max. Discharge Distance	500 m	800 m	1000 m	1500 m	2000 m	3000 m
Installed Power	200 kw	336 kw	559 kw	895 kw	1231 kw	2446 kw
Discharge Pipe Diameter	200 mm	250 mm	300 mm	400 mm	500 mm	600 mm
Cutter Diameter	800 mm	1100 mm	1100 mm	1400 mm	1700 mm	2400 mm
Cutter Power	30 kw	43kw	60 kw	98 kw m	165 kw	220 kw
Ladder Winch Capacity	30 kn	40 kn	50 kn	80 kn	100 kn	160 kn
Swing Winch Capacity	30 kn	40 kn	50 kn	60 kn	80 kn	120 kn
Operation	Hydraulic and PLC control	Hydraulic and PLC control	Hydraulic and PLC control	Hydraulic and PLC control	Hydraulic and PLC control	Hydraulic and PLC control
Max. Fuel Consumption	35-40 l/hr	60-70 l/hr	90-100 l/hr	155-170 l/hr	210-230 l/hr	400-430 l/hr
Weight	35 t	50 t	62 t	98 t	153 t	220 t

After-sale Service
DRAGON customers rely on the unrivalled level of commitment that is offered to them through dedicated and comprehensive life-cycle support services. These help to maximise the equipment's availability and the return on investment, and therefore reduces the total cost of ownership. The cycle can be entered at any of its five integrated stage.

Should you have any interest in our 12inch Customized Cutter Suction Dredger, wish you could feel free to contact us.Your requests are highly welcomed.

Customer feedback
Why You Choose Dragon Dredger

1. Advanced Design
          2. Advanced Equipment and Quality
                 3. Creative Design and Layout
                          4. Considerate Service and Training
                                  5. Competitive Price
                                         6. Extended Warranty
                                                7. Performance Guarantee
                                                       8. Bring Other Cooperation Opportunities
Our Servicea. Standby our dredger expert Team will follow up all our supplied dredger's working condition in certain time. b. Chinese engineers will stay in Bangladesh all the time and give regular inspection and consultation for the clients. Our service staff will be presented at the dredger location within 24 hours if any emergency service needed on the dredger. c. We can supply detailed training to the staff from the clients. During the manufacturing of the dredger, the client can appoint one engineers to stay in our factory and even work with our engineers. Our engineers will train them from starting of the dredger assembling. d. When the dredger is assembled, our engineers will give training program to more staff from the client's company. If more training program needed, our engineers can give regular maintenance training to the client's staff up to their satisfactory level.

Other Products
Dragon products scope covers all kinds of dredger, aquqtic weed harvester, amphibious excavator, workboat, backhoe barge, jack-up platform.
